Product Description
With a robust 8-ton working weight, the Doosan DX80 excavator is a powerful addition to any construction site. Equipped with a Yanmar 4TNV98 VDB24 engine, delivering 41.4 kW at 2100 rpm, this machine ensures reliable performance for digging, grading, and demolition tasks. Located in 浙江温州, it stands ready to tackle your most demanding projects.
- Bucket capacity: 0.30 ~ 0.32 m³, ideal for versatile earthmoving operations.
- Maximum digging depth: 4165 mm, providing deep trenching capabilities.
- Travel speed: 4.9 / 3.1 km/h, ensuring efficient movement around the site.
- Ground specific pressure: 37 Kpa, minimizing ground disturbance.
- Fuel tank: 145 L, allowing for extended operation without refueling.
Designed for immediate deployment, the DX80 offers a maximum tractive force of 63 kN and a bucket digging force of 56 kN, making it a formidable tool for any job. Its compact dimensions and high-performance hydraulics ensure maneuverability and precision in tight spaces. Ready to work, this excavator is an essential asset for enhancing productivity and efficiency on your site.
| Specifications | Value |
|---|---|
| No. | 984325 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
