| Specifications | Value |
|---|---|
| No. | 970694 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 4653 |
| Country of origin | America |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar Yanmar V2403-M-D1-E3B-BC-5 |
| Rated power (kw/rpm) | 30.2/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 87.1 by 102.4 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.3 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 58 |
| Bucket digging force (kN) | 35.8 |
| Rod digging force (kN) | 25.7 |
| Travel speed (km/h) | 2.4/4.2 |
| Maximum flow of main pump (l/min) | 99.1 |
| Fuel Tank (L) | 79.9 |
| Hydraulic Tank (L) | 15.1 |
| Engine Oil changes (L) | 7.1 |
| Coolant (L) | 8.3 |
| Hydraulic System (L) | 54.9 |
| Total transport length (mm) | 5353 |
| Total transport width (mm) | 1960 |
| Total transport height (mm) | 2532 |
| Full cab height (mm) | 2532 |
| Counterweight ground clearance (mm) | 640 |
| Minimum turning radius of front working device (mm) | 2491 |
| Track gauge (mm) | 1560 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 1960 |
| Track ground length (mm) | 1998 |
| Maximum digging radius (mm) | 5802 |
| Maximum digging depth (mm) | 3300 |
| Maximum excavation height (mm) | 5345 |
| Maximum unloading height (mm) | 3697 |
| Maximum vertical digging depth (mm) | 2815 |
| Bulldozer lift or depth (mm) | 384/465 |
| Dodging plate width × height (mm) | 1960 x 446 |
| Maximum excavation radius of stop surface (mm) | 5670 |
| Boom turning Angle (left/right °) | 70/55 |
Description
"Recommendation of High-quality Second-hand Construction Machinery This is a Doosan 75 model excavator that was manufactured in 2019. Its overall condition is in excellent condition, with a condition of 95% new. Since it was put into use, the cumulative working time of this equipment has only been about 1,200 hours, which is far lower than the average service life of similar equipment. Therefore, it is close to brand new in both appearance and performance. In terms of the power system, it adopts an original imported high-performance engine, ensuring the stability and efficiency of the machine under various working conditions. After regular maintenance and upkeep by a professional team, the engine operates smoothly, with low noise and economical fuel consumption. Even under long-term continuous operation, it can maintain good power output, meeting your demands for construction efficiency. The hydraulic system is a major highlight of this excavator. It adopts an advanced closed center load sensitive control system, making the operation more precise and smooth, and the response speed faster. In addition, it is equipped with 45-axis rakes (2 pieces), 45-axis small buckets and 68-axis hammers and other multi-functional attachments, which
