Product Description
The Hitachi 120-6 excavator is highly favored in the market for its outstanding performance and reliable quality. The working time of this device is only 3,000 hours, ensuring its stability and durability during long-term use. In terms of the power system, the Hitachi 120-6 is equipped with an efficient and reliable engine, the expected model is Isuzu 4HK1X, with a maximum output power of up to 95 kilowatts (128 horsepower), featuring excellent fuel economy and strong power output. This enables it to handle various complex working conditions with ease, whether it is excavation, loading or crushing operations, it can perform outstandingly. The hydraulic system is a major highlight of this model, equipped with advanced variable piston pumps and high-performance hydraulic motors, enabling precise control and smooth operation. This design not only enhances work efficiency but also effectively reduces energy consumption and prolongs the service life of the entire machine. In addition, its unique hydraulic oil cooling system further ensures the reliability and stability during long-term operation. As a second-hand construction machinery, the Hitachi 120-6 excavator has many advantages: Firstly, its maintenance and upkeep costs are relativ
| Specifications | Value |
|---|---|
| No. | 976777 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12200 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4.6 |
| Rod length (mm) | 2.52 |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4BG1TC |
| Rated power (kw/rpm) | 66/2150 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 13.7 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 99 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 3.4/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative plunger pump ×1 |
| Type of walking hydraulic motor | Variable piston pump ×2 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable piston pump ×2+ gear pump ×1 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 69(Full box 130) |
| Engine Oil changes (L) | 15.8 |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2740 |
| Full cab height (mm) | 2740 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2880 |
| Maximum digging radius (mm) | 8270 |
| Maximum digging depth (mm) | 5570 |
| Maximum excavation height (mm) | 8570 |
| Maximum unloading height (mm) | 6160 |
| Maximum vertical digging depth (mm) | 5020 |
| Bulldozer lift or depth (mm) | No bulldozer |
