2016 Hitachi ZX120

1/6
Used Hitachi ZX120 Excavator 2016 Model / 1
Used Hitachi ZX120 Excavator 2016 Model / 2
Used Hitachi ZX120 Excavator 2016 Model / 3
Used Hitachi ZX120 Excavator 2016 Model / 4
Used Hitachi ZX120 Excavator 2016 Model / 5
Used Hitachi ZX120 Excavator 2016 Model / 6

Product Description

This second-hand Hitachi 120/6 excavator, with its outstanding performance and reliable quality, is the ideal choice for your engineering projects. This equipment has only been in use for approximately 4,000 hours and is in good working condition, ensuring its continuous and efficient operation in future projects. In terms of the power system, this machine is equipped with the original high-quality Hitachi engine, model ISUZU AH-4HK1X, with a rated power of 75kW (102 horsepower), ensuring strong power output and excellent fuel economy. Whether facing complex terrains or high-intensity tasks, it can handle them with ease and provide stable and reliable power support. The hydraulic system adopts advanced negative flow control technology. The main pump is a high-pressure variable piston pump produced by Hitachi, with a maximum flow rate of up to 130L/min. Combined with an efficient hydraulic motor and valve group design, it achieves precise and rapid operation response, reduces energy consumption loss, and improves overall work efficiency. In addition, this system also features excellent heat dissipation performance, effectively extending the service life of key components. As a classic model that has been tested by the market for a lo

SpecificationsValue
No.978719
Tonnage (tons)12
Working weight (kg)12200
Bucket capacity (m³)0.52
Boom length (mm)4.6
Rod length (mm)2.52
Country of originHefei, Anhui Province
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeISUZU CC-4BG1TC
Rated power (kw/rpm)66/2150
Cooling modewater-cooling
Number of cylinders (PCS)4
Displacement (L)4.329
Working formDirect injection
Ground specific pressure (Kpa)37
Rotation speed (rpm)13.7
Climbing ability (%)70/35 °
Bucket digging force (kN)99
Rod digging force (kN)65
Travel speed (km/h)3.4/5.5
Main overflow set pressure (Mpa)34.3
Rotary hydraulic motor typeQuantitative plunger pump ×1
Type of walking hydraulic motorVariable piston pump ×2
Hydraulic crushing pipeline is standardno
Main pump typeVariable piston pump ×2+ gear pump ×1
Fuel Tank (L)250
Hydraulic Tank (L)69(Full box 130)
Engine Oil changes (L)15.8
Total transport length (mm)7610
Total transport width (mm)2490
Total transport height (mm)2740
Full cab height (mm)2740
Counterweight ground clearance (mm)890
Minimum ground clearance (mm)440
Back end turning radius (mm)2130
Total track length (mm)3580
Track gauge (mm)1990
Track plate width (mm)500
Total track width (mm)2490
Track ground length (mm)2880
Maximum digging radius (mm)8270
Maximum digging depth (mm)5570
Maximum excavation height (mm)8570
Maximum unloading height (mm)6160
Maximum vertical digging depth (mm)5020
Bulldozer lift or depth (mm)No bulldozer
see more

Overview

No.978719

Brand Name:

Hitachi

Model Number:

ZX120

Year:

2016

Location:

Fujian China
