Product Description
This is a second-hand Hitachi ZX120-6 excavator of the 2015 model, with a cumulative working time of approximately 3,000 hours (possibly), and its overall condition is excellent. This equipment is equipped with a high-performance engine imported from Hitachi, model Isuzu 4HK1XKSA-01, with a rated power of up to 70kW. It is powerful and has excellent fuel economy, ensuring efficient operation while reducing operating costs. In terms of the hydraulic system, this machine is equipped with Hitachi's advanced negative flow control system and a large-capacity hydraulic pump, combined with a high-quality hydraulic motor, making the operation smoother and more precise. Whether it is digging or loading, it can handle it with ease. More importantly, this meticulously tuned hydraulic system has significantly enhanced work efficiency, reduced energy loss, and further improved economic benefits. In addition, this excavator adopts a newly replaced chassis structure, which not only enhances the overall stability of the machine but also extends its service life. The entire vehicle remains in its original condition, with a clean and beautiful appearance, no obvious bumps or damages, and the interior is well maintained. The driving environment is comf
| Specifications | Value |
|---|---|
| No. | 978895 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12200 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4.6 |
| Rod length (mm) | 2.52 |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4BG1TC |
| Rated power (kw/rpm) | 66/2150 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 13.7 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 99 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 3.4/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative plunger pump ×1 |
| Type of walking hydraulic motor | Variable piston pump ×2 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable piston pump ×2+ gear pump ×1 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 69(Full box 130) |
| Engine Oil changes (L) | 15.8 |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2740 |
| Full cab height (mm) | 2740 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2880 |
| Maximum digging radius (mm) | 8270 |
| Maximum digging depth (mm) | 5570 |
| Maximum excavation height (mm) | 8570 |
| Maximum unloading height (mm) | 6160 |
| Maximum vertical digging depth (mm) | 5020 |
| Bulldozer lift or depth (mm) | No bulldozer |
