| Specifications | Value |
|---|---|
| No. | 962790 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
Description
Hitachi ZX200-5A Excavator This second-hand Hitachi ZX200-5A excavator, produced in 2016, has only been in operation for 7,000 hours so far. With a medium to low usage intensity and proper maintenance, its overall performance remains excellent. It was originally quite expensive, but now you can get the car for just 607,000 yuan, offering an extremely high cost performance. In terms of the power system, this aircraft is equipped with a highly efficient and energy-saving engine independently developed by Hitachi, which is powerful and has low fuel consumption, meeting the National III emission standards. It can maintain stable output even under harsh working conditions and easily handle various complex terrains and heavy-load operation requirements. In addition, its advanced fuel management system can effectively reduce operating costs and improve economic benefits. The hydraulic system is a major highlight of this excavator. It adopts the latest generation of HIOS III hydraulic technology, which not only has a fast response speed and flexible and precise operation, but also greatly improves work efficiency. Whether it is digging, loading or crushing tasks, they can all be accomplished with ease, creating more value for users. In conc
