| Specifications | Value |
|---|---|
| No. | 967273 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
Description
【 Premium Recommendation 】 Second-hand Hitachi ZX60 excavator from 2015 This second-hand Hitachi ZX60 excavator from 2015 is a high-quality machine that is rarely seen in the market. It not only has outstanding performance, but also does a very good job in maintenance and upkeep. The total working time is only 4,500 hours, which is far lower than the average service life of similar machines. This means that it still has a long service life to be explored. In terms of the power system, this excavator is equipped with an original imported high-efficiency and energy-saving engine from Hitachi. This engine features powerful torque output and smooth operation characteristics, maintaining a stable working state even in harsh working environments. Meanwhile, advanced fuel injection technology leads to lower fuel consumption, saving users a significant amount of operating costs. The hydraulic system is a major highlight of this excavator. It adopts Hitachi's unique HIOS III hydraulic control system, which has a fast response speed, flexible and precise operation, and can easily meet the operation requirements in various complex terrains. In addition, the efficient cooling device ensures that the hydraulic oil temperature remains within the
