| Specifications | Value |
|---|---|
| No. | 967882 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
Description
"Recommendation of Premium Second-hand Excavators We have carefully prepared a high-quality second-hand excavator for you, model Calendar 360/5A. Since its commissioning, this excavator has accumulated a working time of only 4,000 hours, which is far lower than the average service life of similar equipment, ensuring its good mechanical condition and long service life. This excavator is equipped with a high-performance Cummins engine as the core of its power system. It not only has strong power and a rapid response, but also has excellent fuel economy. While ensuring efficient operation, it effectively reduces operating costs. In terms of the hydraulic system, it is equipped with an advanced load-sensitive control system, which makes the operation more stable and smooth, greatly improving work efficiency and accuracy. In addition, it is equipped with a sturdy and durable large-capacity bucket (5A), which is particularly suitable for earthwork excavation tasks under heavy-load conditions. Whether it is digging hard soil or handling large pieces of materials, it can handle them with ease, greatly improving construction efficiency. In conclusion, this second-hand calendar 360/5A excavator, with its outstanding performance, reliable qualit
