Product Description
This second-hand Hitachi ZX60-3 excavator, manufactured in 2013, has a service life of approximately 5,000 hours. This equipment is renowned for its outstanding performance and reliability, making it an ideal choice for small and medium-sized engineering projects. In terms of the power system, the Hitachi ZX60-3 is equipped with a highly efficient and reliable Yanmar 4TNV98 engine, with a maximum power output of up to 40.5 kilowatts. This four-cylinder turbocharged diesel engine not only offers powerful output but also features excellent fuel economy, ensuring cost-effectiveness during long-term operation. In addition, its advanced emission control system also complies with strict environmental protection standards. The hydraulic system is another major highlight of this excavator. Equipped with a high-performance variable piston pump and hydraulic motor combination, the entire machine operates more flexibly and precisely. Whether in excavation, loading or crushing operations, it can demonstrate outstanding work efficiency and stability. Meanwhile, the application of intelligent flow control technology has further enhanced the system's response speed and overall energy efficiency ratio. As a classic model that has been verified by t
| Specifications | Value |
|---|---|
| No. | 975895 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
