Product Description
For sale a second-hand Hitachi 360-3G excavator with a working time of only single-digit hours and almost brand new. This excavator is equipped with a powerful power system and adopts an original imported efficient engine from Hitachi. The expected model is ISUZU AH-6HK1X, with a rated power of approximately 270 horsepower (possibly), ensuring outstanding performance and reliable operation. This model is renowned for its outstanding fuel economy and low emissions. While ensuring strong digging power, it also pays attention to environmental protection. In terms of the hydraulic system, this excavator is equipped with an advanced dual-pump and dual-loop constant power regulation system, which can automatically adjust the flow distribution according to the operation requirements and improve work efficiency. The main pump is equipped with a high-quality variable piston pump and a high-performance hydraulic motor, ensuring that the machine maintains stable operating performance and smooth action response even under complex working conditions. In addition, the Hitachi 360-3G also features a number of humanized designs: the spacious and comfortable cab provides a good field of vision; The intelligent control system simplifies the operation
| Specifications | Value |
|---|---|
| No. | 976723 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
