| Specifications | Value |
|---|---|
| No. | 966520 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 6510 |
| Bucket capacity (m³) | 0.3 |
| Boom length (mm) | 3.72 |
| Rod length (mm) | 1.62(reinforced type) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.318 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 30 |
| Rotation speed (rpm) | 11.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 55 |
| Rod digging force (kN) | 38 |
| Travel speed (km/h) | 3.4/5.0 |
| Main overflow set pressure (Mpa) | 31.4 |
| Rotary hydraulic motor type | Variable piston pump ×1 |
| Type of walking hydraulic motor | Variable piston pump ×2 |
| Main pump type | Variable piston pump ×3+ gear pump ×1 |
| Fuel Tank (L) | 135 |
| Hydraulic Tank (L) | 60(over 100) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6080 |
| Total transport width (mm) | 2260 |
| Total transport height (mm) | 2600 |
| Full cab height (mm) | 2600 |
| Counterweight ground clearance (mm) | 760 |
| Minimum ground clearance (mm) | 360 |
| Back end turning radius (mm) | 1750 |
| Total track length (mm) | 2765 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2200 |
| Track ground length (mm) | 2140 |
| Maximum digging radius (mm) | 6320 |
| Maximum digging depth (mm) | 4170 |
| Maximum excavation height (mm) | 7150 |
| Maximum unloading height (mm) | 5060 |
| Maximum vertical digging depth (mm) | 3730 |
| Bulldozer lift or depth (mm) | No bulldozer |
Description
Detailed Introduction of the second-hand Hitachi 70 Excavator Dear customer, hello! We currently have a batch of second-hand Hitachi 70 excavators. All these devices are imported through regular channels and have undergone professional testing and maintenance. They are stable and reliable in performance and are very suitable for the operation needs of various small and medium-sized projects. The following is detailed information about this classic model: - ** Working hours ** : The working hours of this batch of Hitachi 70 excavators range from 2,000 to 3,500 hours, which falls within the medium to low usage frequency range. This means they still have a long service life waiting for you to excavate. - ** Power System ** : Equipped with a highly efficient and energy-saving engine specially designed by Hitachi for small excavators, it not only has strong power but also low fuel consumption, effectively reducing operating costs while ensuring operational efficiency. In addition, this engine also has excellent low-temperature starting performance and can handle even in cold regions with ease. - ** Hydraulic System ** : Advanced negative flow control technology is adopted to ensure smoother operation and rapid response. It is also equip
