Product Description
【 Premium Recommendation 】 A second-hand Hitachi ZX70 excavator produced in 2008, with a service life of only 15 years and an estimated cumulative usage time of 6,000 hours. It features stable and reliable performance and is exempt from inspection. This device is equipped with a well-tested Hitachi original engine, model 4D52T-E23, with a maximum power output of up to 40kW, ensuring strong power output and smooth operation performance. In terms of the hydraulic system, a combination of highly efficient and energy-saving variable piston pumps and high-quality hydraulic motors is adopted. This not only enhances the operational efficiency but also effectively reduces energy consumption and extends the service life of the machine. This excavator is specially equipped with a bulldozer blade device, which greatly facilitates the cleaning and leveling work at the construction site and enhances the multi-functionality and practicality of the equipment. In addition, its robust and durable structural design, user-friendly operation interface and excellent control performance make this Hitachi ZX70 an ideal choice for small and medium-sized engineering projects. Whether it is urban construction or rural infrastructure building, it can easily han
| Specifications | Value |
|---|---|
| No. | 978932 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 6510 |
| Bucket capacity (m³) | 0.3 |
| Boom length (mm) | 3.72 |
| Rod length (mm) | 1.62(reinforced type) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.318 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 30 |
| Rotation speed (rpm) | 11.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 55 |
| Rod digging force (kN) | 38 |
| Travel speed (km/h) | 3.4/5.0 |
| Main overflow set pressure (Mpa) | 31.4 |
| Rotary hydraulic motor type | Variable piston pump ×1 |
| Type of walking hydraulic motor | Variable piston pump ×2 |
| Main pump type | Variable piston pump ×3+ gear pump ×1 |
| Fuel Tank (L) | 135 |
| Hydraulic Tank (L) | 60(over 100) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6080 |
| Total transport width (mm) | 2260 |
| Total transport height (mm) | 2600 |
| Full cab height (mm) | 2600 |
| Counterweight ground clearance (mm) | 760 |
| Minimum ground clearance (mm) | 360 |
| Back end turning radius (mm) | 1750 |
| Total track length (mm) | 2765 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2200 |
| Track ground length (mm) | 2140 |
| Maximum digging radius (mm) | 6320 |
| Maximum digging depth (mm) | 4170 |
| Maximum excavation height (mm) | 7150 |
| Maximum unloading height (mm) | 5060 |
| Maximum vertical digging depth (mm) | 3730 |
| Bulldozer lift or depth (mm) | No bulldozer |
