Product Description
This 2017 Hyundai R110-9A excavator has a cumulative working time of only over 120,000 hours, and its overall condition is maintained in excellent condition. It is equipped with a high-performance Cummins B3.3 engine, with a maximum output power of 55 kilowatts. It is powerful and has excellent fuel economy, ensuring efficient operation under various working conditions. In terms of the hydraulic system, this equipment is equipped with an advanced Kawasaki K3V series main pump and motor combination, providing a stable and precise operation experience. Its efficient hydraulic control system not only enhances the digging force but also significantly reduces energy consumption, making the operation smoother and more fluid. In addition, it is expected that this model may also be equipped with an automatic idle function, which automatically reduces the engine speed when not in operation to save fuel consumption. As a compact excavator, the Hyundai R110-9A is renowned for its outstanding flexibility and is suitable for precise operations in confined Spaces. Meanwhile, its robust and durable design enables it to easily cope with harsh working environments. The spacious and comfortable cab, humanized control layout and all-round safety protec
| Specifications | Value |
|---|---|
| No. | 978008 |
| Tonnage (tons) | 11 |
| Bucket capacity (m³) | 0.45m3 |
| Boom length (mm) | 4300mm |
| Rod length (mm) | 2260mm |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | MITSUBISHI 4FRC |
| Rated power (kw/rpm) | 99(74) / 2000 |
| Cylinder diameter × stroke (mm) | 102 (4.02) x 130 (5.12) |
| Maximum torque (N.m) | 43.5(315) / 1350 |
| Displacement (L) | 4.2 |
| Working form | 4 cylinder 4 stroke water cooled direct injection engine |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.5 km/h (3.4 mph) / 3.4 km/h (2.1 mph) |
| Maximum flow of main pump (l/min) | 2×112 (2×29.6) |
| Traveling Hydraulic Circuit (Mpa) | 330 |
| Rotary Hydraulic Circuit (Mpa) | 240 |
| Main pump type | Two variable plunger pump |
| Working Hydraulic Circuit (Mpa) | 330 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-95 x 65 x 855 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-110 x 75 x 1070 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-95 x 70 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 100 |
| Engine Oil changes (L) | 17.5 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 210 |
| Full cab height (mm) | 2800 |
| Counterweight ground clearance (mm) | 900 |
| Back end turning radius (mm) | 2380mm |
| Total track length (mm) | 7270 |
| Total track width (mm) | 2490 |
| Maximum digging radius (mm) | 7740mm |
| Maximum digging depth (mm) | 5090mm |
| Maximum excavation height (mm) | 8070mm |
| Maximum unloading height (mm) | 5710mm |
| Maximum vertical digging depth (mm) | 4430mm |
| Maximum excavation radius of stop surface (mm) | 7610mm |
