Product Description
The modern R150 second-hand excavator has a cumulative working time of only 60,000 hours, which indicates that it still maintains a good operating condition and a relatively long service life. This model is equipped with an efficient and reliable engine. Although the specific model has not been given, based on the common configurations in the market, it might be a well-tested Cummins or Mitsubishi series engine, with an estimated power of approximately 83-90 kilowatts, ensuring strong power output and smooth working performance. In terms of the hydraulic system, this machine is equipped with an advanced load-sensing hydraulic pump and a high-quality hydraulic motor combination. This system can achieve precise and rapid operation response, and can handle excavation, loading and crushing operations with ease. In addition, its optimized design has significantly improved fuel efficiency and reduced operating costs. As a medium-sized excavator, the Hyundai R150 not only boasts excellent stability and flexibility but also features a spacious and comfortable cab environment, providing the operator with an outstanding working experience. The robust and durable structural design, combined with the feature of easy maintenance, makes it an idea
| Specifications | Value |
|---|---|
| No. | 976192 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 13740 |
| Bucket capacity (m³) | 0.58 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2100 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins F4.5 |
| Rated power (kw/rpm) | 125/2200 |
| Total displacement (L) | 4.5 |
| Cylinder diameter × stroke (mm) | 107*124 |
| Maximum torque (N.m) | 670/1300 |
| Number of cylinders (PCS) | 4 |
| Forward speed (Km/h) | 10/39.5 |
| Rotation speed (rpm) | 11.3 |
| Maximum flow of main pump (l/min) | 2*160 |
| Fuel Tank (L) | 270 |
| Hydraulic Tank (L) | 114 |
| Engine Oil changes (L) | 14 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 210 |
| Total transport length (mm) | 7850 |
| Total transport width (mm) | 2510 |
| Total transport height (mm) | 3160 |
| Full cab height (mm) | 3160 |
| Counterweight ground clearance (mm) | 1250 |
| Wheelbase (mm) | 2800 |
| Wheel base (mm) | 1945 |
| Minimum ground clearance (mm) | 340 |
| Onboard width (mm) | 2510 |
| Maximum digging radius (mm) | 7920 |
| Maximum excavation radius (mm) | 7700 |
| Maximum digging depth (mm) | 4820 |
| Maximum excavation height (mm) | 8500 |
| Maximum unloading height (mm) | 6070 |
| Maximum vertical digging depth (mm) | 4380 |
| Minimum turning radius (mm) | 2655 |
