Product Description
Skip the factory lead times with this 2018 Hyundai R130VS excavator, available now in Guizhou Province for immediate deployment to your construction site. Built for demanding operations, this 13-ton machine delivers reliable performance with its Mitsubishi D04FRC-TAA engine producing 98kW of power and maximum torque of 492 N·m at 1350 rpm.
Engineered for versatility and efficiency, the R130VS features a 0.52m³ bucket capacity and impressive reach specifications including 8.33m maximum digging radius and 5.55m maximum digging depth. Advanced hydraulic systems with dual variable plunger pumps ensure smooth operation across challenging terrain, while the robust undercarriage with 44 track plates per side provides exceptional stability.
- 13-ton working weight with 4600mm boom and 2500mm arm configuration
- Mitsubishi turbocharged engine with water cooling system
- 270L fuel capacity for extended operation cycles
- 70% climbing ability and 5.5 km/h travel speed
- Ready for immediate shipment from Guizhou location
Avoid production delays and secure this proven excavator for fast deployment to your project site.
| Specifications | Value |
|---|---|
| No. | 981760 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13000 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi D04FRC-TAA |
| Rated power (kw/rpm) | 98/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 120 |
| Maximum torque (N.m) | 49.2/1350 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.25 |
| Working form | 4 cylinder, 4 stroke, turbocharged air-to-air cooled engine |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.5 / 3.2 |
| Rotary hydraulic motor type | Axial piston motor with automatic braking |
| Type of walking hydraulic motor | Two-speed axial plunger motor with brake valve and parking brake |
| Maximum flow of main pump (l/min) | 2 x 124 |
| Main pump type | Two variable plunger pump |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 - ø 100 x ø 70 x 840 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 - ø 115 x ø 80 x 1138 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 - ø 105 x ø 75 x 1075 |
| Pilot pump type | Gear pump |
| Fuel Tank (L) | 270 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 17.5 |
| Coolant (L) | 15.5 |
| Hydraulic System (L) | 210 |
| Total transport length (mm) | 7820 |
| Total transport width (mm) | 2500 |
| Total transport height (mm) | 2780 |
| Full cab height (mm) | 2775 |
| Counterweight ground clearance (mm) | 940 |
| Back end turning radius (mm) | 2330 |
| Onboard width (mm) | 2476 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 6 |
| Number of track plates (single side) (PCS) | 44 |
| Maximum digging radius (mm) | 8330 |
| Maximum digging depth (mm) | 5550 |
| Maximum excavation height (mm) | 8500 |
| Maximum unloading height (mm) | 6060 |
| Maximum vertical digging depth (mm) | 5330 |
| Maximum excavation radius of stop surface (mm) | 8180 |
