| Specifications | Value |
|---|---|
| No. | 962577 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 13700 |
| Bucket capacity (m³) | 0.23-0.71 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2100 |
| Country of origin | Peking |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins B5.9-C |
| Rated power (kw/rpm) | 112/1950 |
| Total displacement (L) | 5.9 |
| Cooling mode | water-cooling |
| remark | Six-cylinder four-stroke turbocharged direct injection engine |
| Maximum torque (N.m) | 613.48 |
| Number of cylinders (PCS) | 6 |
| Forward speed (Km/h) | 37 |
| Rotation speed (rpm) | 13 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 101.9 |
| Rod digging force (kN) | 65.6 |
| Maximum tractive force (kN) | 83.3 |
| Driving form | Hydraulic motor |
| Main overflow set pressure (Mpa) | 350 |
| Rotary hydraulic motor type | Variable swash plate plunger motor |
| Maximum flow of main pump (l/min) | 2 x 168 |
| Main pump type | Variable swash plate piston pump |
| Working Hydraulic Circuit (Mpa) | Quantitative swash plate plunger motor |
| Fuel Tank (L) | 270 |
| Hydraulic Tank (L) | 126 |
| Total transport length (mm) | 7760 |
| Total transport width (mm) | 2500 |
| Total transport height (mm) | 3500 |
| Full cab height (mm) | 3137 |
| Counterweight ground clearance (mm) | 1233 |
| Wheelbase (mm) | 2800 |
| Single tire width (mm) | 900×20-14PR |
| Total tire outside width (mm) | 2495 |
| Wheel base (mm) | 1944 |
| Minimum ground clearance (mm) | 365 |
| Onboard width (mm) | 2500 |
| Maximum digging radius (mm) | 7920 |
| Maximum excavation radius (mm) | 7700 |
| Maximum digging depth (mm) | 4850 |
| Maximum excavation height (mm) | 8470 |
| Maximum unloading height (mm) | 6040 |
| Maximum vertical digging depth (mm) | 4460 |
| Minimum turning radius (mm) | 2670 |
| Dodging plate width × height (mm) | 2490 x 559 |
Description
【 Premium Modern 150-9 Excavator We present to you a well-maintained second-hand modern 150-9 excavator. This machine not only has an excellent appearance but also outstanding performance, making it an ideal choice for your engineering operations. The total working hours of this equipment are only 3,500 hours, which means it is still in the golden stage of its mechanical life cycle and can provide stable and reliable services. "Power System This machine is equipped with a highly efficient and energy-saving engine, ensuring outstanding power performance under all working conditions. Whether it's flat ground excavation or complex terrain operations, this engine can handle them with ease while maintaining a low fuel consumption level, helping you save operating costs. "Hydraulic System The adoption of advanced hydraulic technology makes the operation more smooth and precise. The powerful digging force combined with the sensitive action response speed enables it to handle even hard soil with ease. In addition, the optimized design of the hydraulic system has effectively reduced noise pollution and enhanced driving comfort. 【 Appearance and Accessories The entire machine's paint surface is as smooth as new, with no obvious scratches or
