| Specifications | Value |
|---|---|
| No. | 962858 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 13700 |
| Bucket capacity (m³) | 0.23-0.71 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2100 |
| Country of origin | Peking |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins B5.9-C |
| Rated power (kw/rpm) | 112/1950 |
| Total displacement (L) | 5.9 |
| Cooling mode | water-cooling |
| remark | Six-cylinder four-stroke turbocharged direct injection engine |
| Maximum torque (N.m) | 613.48 |
| Number of cylinders (PCS) | 6 |
| Forward speed (Km/h) | 37 |
| Rotation speed (rpm) | 13 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 101.9 |
| Rod digging force (kN) | 65.6 |
| Maximum tractive force (kN) | 83.3 |
| Driving form | Hydraulic motor |
| Main overflow set pressure (Mpa) | 350 |
| Rotary hydraulic motor type | Variable swash plate plunger motor |
| Maximum flow of main pump (l/min) | 2 x 168 |
| Main pump type | Variable swash plate piston pump |
| Working Hydraulic Circuit (Mpa) | Quantitative swash plate plunger motor |
| Fuel Tank (L) | 270 |
| Hydraulic Tank (L) | 126 |
| Total transport length (mm) | 7760 |
| Total transport width (mm) | 2500 |
| Total transport height (mm) | 3500 |
| Full cab height (mm) | 3137 |
| Counterweight ground clearance (mm) | 1233 |
| Wheelbase (mm) | 2800 |
| Single tire width (mm) | 900×20-14PR |
| Total tire outside width (mm) | 2495 |
| Wheel base (mm) | 1944 |
| Minimum ground clearance (mm) | 365 |
| Onboard width (mm) | 2500 |
| Maximum digging radius (mm) | 7920 |
| Maximum excavation radius (mm) | 7700 |
| Maximum digging depth (mm) | 4850 |
| Maximum excavation height (mm) | 8470 |
| Maximum unloading height (mm) | 6040 |
| Maximum vertical digging depth (mm) | 4460 |
| Minimum turning radius (mm) | 2670 |
| Dodging plate width × height (mm) | 2490 x 559 |
Description
【 Premium Recommendation 】 The second-hand Hyundai 150-9 excavator is in excellent condition and performance, with a working time of only 2,500 hours. It is your ideal choice for engineering operations. The power system of this excavator is equipped with a high-performance engine, which is powerful, stable and reliable. It can easily handle various complex working conditions. Whether it is earthwork excavation or rock crushing, it can handle it with ease. The hydraulic system has been meticulously maintained, featuring a sensitive response and smooth operation, ensuring high working efficiency and a low failure rate, significantly reducing your operating costs. In terms of appearance, this excavator has undergone professional refurbishment and "put on" a "new coat", not only looking brand new but also effectively extending its service life. More importantly, due to its outstanding performance and low depreciation rate, this device has a very high return on investment, making it highly suitable for buyers who are seeking cost-effectiveness and a quick return on investment. The current price is only 78,000 RMB. It's a rare opportunity! If you are looking for a high-performance and cost-effective second-hand excavator to boost your busi
