| Specifications | Value |
|---|---|
| No. | 964336 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 13700 |
| Bucket capacity (m³) | 0.23-0.71 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2100 |
| Country of origin | Peking |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins B5.9-C |
| Rated power (kw/rpm) | 112/1950 |
| Total displacement (L) | 5.9 |
| Cooling mode | water-cooling |
| remark | Six-cylinder four-stroke turbocharged direct injection engine |
| Maximum torque (N.m) | 613.48 |
| Number of cylinders (PCS) | 6 |
| Forward speed (Km/h) | 37 |
| Rotation speed (rpm) | 13 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 101.9 |
| Rod digging force (kN) | 65.6 |
| Maximum tractive force (kN) | 83.3 |
| Driving form | Hydraulic motor |
| Main overflow set pressure (Mpa) | 350 |
| Rotary hydraulic motor type | Variable swash plate plunger motor |
| Maximum flow of main pump (l/min) | 2 x 168 |
| Main pump type | Variable swash plate piston pump |
| Working Hydraulic Circuit (Mpa) | Quantitative swash plate plunger motor |
| Fuel Tank (L) | 270 |
| Hydraulic Tank (L) | 126 |
| Total transport length (mm) | 7760 |
| Total transport width (mm) | 2500 |
| Total transport height (mm) | 3500 |
| Full cab height (mm) | 3137 |
| Counterweight ground clearance (mm) | 1233 |
| Wheelbase (mm) | 2800 |
| Single tire width (mm) | 900×20-14PR |
| Total tire outside width (mm) | 2495 |
| Wheel base (mm) | 1944 |
| Minimum ground clearance (mm) | 365 |
| Onboard width (mm) | 2500 |
| Maximum digging radius (mm) | 7920 |
| Maximum excavation radius (mm) | 7700 |
| Maximum digging depth (mm) | 4850 |
| Maximum excavation height (mm) | 8470 |
| Maximum unloading height (mm) | 6040 |
| Maximum vertical digging depth (mm) | 4460 |
| Minimum turning radius (mm) | 2670 |
| Dodging plate width × height (mm) | 2490 x 559 |
Description
"Modern 150-9 second-hand excavator for sale Dear customer, hello! We currently have a high-quality second-hand Hyundai 150-9 excavator for sale. This excavator originally belonged to a well-managed construction company, but due to the company's business adjustment, it had to be given up with great reluctance. This device not only has a neat and new appearance but also outstanding performance, making it an ideal choice for your engineering work. 【 Basic Information - Working hours: It only operated for about 3,000 hours, which is far shorter than the average service life of similar machinery, ensuring a relatively long remaining service life. - Price: 78,000 RMB. It offers an extremely high cost performance and is suitable for friends with a limited budget but who still pursue efficient operation. "Power System Equipped with a powerful and reliable engine, it starts quickly and runs smoothly, maintaining stable output even under harsh working conditions. After professional inspection, the engine is in good condition with no obvious signs of wear or malfunction. "Hydraulic System Adopting advanced hydraulic technology, it features a fast response speed and high control accuracy, making it capable of handling both excavation and load
