2016 Hyundai R215-7

1/8
Used Hyundai R215-7 Excavator 2016 Model / 1
Used Hyundai R215-7 Excavator 2016 Model / 2
Used Hyundai R215-7 Excavator 2016 Model / 3
Used Hyundai R215-7 Excavator 2016 Model / 4
Used Hyundai R215-7 Excavator 2016 Model / 5
Used Hyundai R215-7 Excavator 2016 Model / 6
Used Hyundai R215-7 Excavator 2016 Model / 7
Used Hyundai R215-7 Excavator 2016 Model / 8

Product Description

【 Premium Recommendation 】 Hyundai 215-7 Black Diamond Excavator, this is a high-performance second-hand excavator that has received high praise in the market. This machine has a cumulative working time of only 4,000 hours and is in the best usage condition, almost equivalent to a nearly new car, with an extremely high cost performance. The overall paint finish of the machine is well maintained, with no obvious scratches or rust, giving people a brand-new visual experience. In terms of power, this model is equipped with a powerful and reliable Cummins engine, with a maximum output power of up to 130kW (approximately 174 horsepower). It not only provides abundant power support but also performs well in fuel economy, effectively reducing operating costs. More importantly, this engine has been meticulously maintained and operates smoothly and quietly without any abnormal noise or vibration. The hydraulic system adopts components of internationally renowned brands, ensuring efficient and stable working performance. Both the digging force and the rotation speed have reached the leading level in the industry, making it particularly suitable for complex and changeable construction environments. In addition, the vehicle is equipped with a 14

SpecificationsValue
No.971316
Tonnage (tons)21
Working weight (kg)20700
Bucket capacity (m³)0.92
Boom length (mm)5650
Rod length (mm)2920
Country of originJiangsu (Province)
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeHyundai D6BT-C
Rated power (kw/rpm)110/1950
Cooling modewater-cooling
Cylinder diameter × stroke (mm)118 x 115
Number of cylinders (PCS)6
Displacement (L)7
Working formSix-cylinder four-stroke turbocharged direct injection engine
Ground specific pressure (Kpa)47
Rotation speed (rpm)12.5
Climbing ability (%)70/35 °
Bucket digging force (kN)123.3
Rod digging force (kN)95.1
Travel speed (km/h)3.5/5.2
Main overflow set pressure (Mpa)47
Rotary hydraulic motor typeQuantitative swash plate axial piston motor
Type of walking hydraulic motorVariable swash plate axial piston motor
Maximum flow of main pump (l/min)2 x 220
Traveling Hydraulic Circuit (Mpa)280
Rotary Hydraulic Circuit (Mpa)240
Main pump type2× variable axial piston pump + gear pump
Working Hydraulic Circuit (Mpa)280
Pilot Oil Circuit (MPa)35
Bucket cylinders - Number × diameter × stroke (mm)120 * 80 * 1120
Bucket rod cylinders - Number × diameter × stroke (mm)140 * 95 * 1570
Boom cylinders - Number × diameter × stroke (mm)125 * 85 * 1320
Fuel Tank (L)320
Hydraulic Tank (L)165
Engine Oil changes (L)16.3
Coolant (L)32.7
Hydraulic System (L)270
Total transport length (mm)9510
Total transport width (mm)2800
Total transport height (mm)2990
Full cab height (mm)2920
Counterweight ground clearance (mm)1060
Minimum ground clearance (mm)480
Back end turning radius (mm)2830
Total track length (mm)4160
Track gauge (mm)2200
Track plate width (mm)600
Total track width (mm)2800
Track ground length (mm)3360
Maximum digging radius (mm)9930
Maximum digging depth (mm)6800
Maximum excavation height (mm)9730
Maximum unloading height (mm)6910
Maximum vertical digging depth (mm)6060
Bulldozer lift or depth (mm)There is no
Dodging plate width × height (mm)There is no
Maximum excavation radius of stop surface (mm)9760
Maximum effective digging depth (mm)6610
see more

Overview

No.971316

Brand Name:

Hyundai

Model Number:

R215-7

Year:

2016

Location:

Jiangxi China
