2019 Hyundai R215VS

1/9
Used Hyundai R215VS Excavator 2019 Model / 1
Used Hyundai R215VS Excavator 2019 Model / 2
Used Hyundai R215VS Excavator 2019 Model / 3
Used Hyundai R215VS Excavator 2019 Model / 4
Used Hyundai R215VS Excavator 2019 Model / 5
Used Hyundai R215VS Excavator 2019 Model / 6
Used Hyundai R215VS Excavator 2019 Model / 7
Used Hyundai R215VS Excavator 2019 Model / 8
Used Hyundai R215VS Excavator 2019 Model / 9

Product Description

【 Premium Recommendation 】 Hyundai 215VS second-hand excavator, manufactured at the end of 2019, genuine vehicle and real appearance, absolutely pure earthwork operation, no experience in high-intensity work such as mining and demolition. The entire machine has only been in operation for 3,600 hours. With proper maintenance, it is in excellent condition and is a rare high-quality second-hand excavator on the market. This excavator is equipped with a Cummins engine that has been well-tested in the market. It is powerful, stable and reliable, and can handle both hard soil layers and soft sand with ease. Meanwhile, the low fuel consumption design enables it to maintain a relatively low operating cost even during long-term operation, saving expenses for users. In addition, it is equipped with an advanced hydraulic system, which is flexible and precise to operate and responds quickly. Even novice drivers can quickly get the hang of it, greatly improving work efficiency and construction quality. We promise that all the displayed data are true records and contain no false elements. As such high-quality second-hand equipment is extremely scarce in the market, once missed, it may be very difficult to find such a cost-effective option again. I

SpecificationsValue
No.971072
Tonnage (tons)21
Working weight (kg)20900
Bucket capacity (m³)0.92
Boom length (mm)5650
Rod length (mm)2920
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeCummins QSB7
Rated power (kw/rpm)125 / 1900
Cooling modewater-cooling
Cylinder diameter × stroke (mm)107 x 124
Maximum torque (N.m)63 / 1500
Number of cylinders (PCS)6
Displacement (L)6.7
Working form6-cylinder, 4-stroke, water-cooled turbocharged engine
Rotation speed (rpm)11.4
Climbing ability (%)70
Travel speed (km/h)5.6 / 3.7
Rotary hydraulic motor typeAxial piston motor with automatic braking
Type of walking hydraulic motorTwo-speed axial plunger motor with brake valve and parking brake
Maximum flow of main pump (l/min)2 x 222
Traveling Hydraulic Circuit (Mpa)350
Rotary Hydraulic Circuit (Mpa)250
Main pump typeTwo variable plunger pump
Working Hydraulic Circuit (Mpa)300
Pilot Oil Circuit (MPa)35
Bucket cylinders - Number × diameter × stroke (mm)1 - ø 120 x ø 80 x 1120
Bucket rod cylinders - Number × diameter × stroke (mm)1 - ø 140 x ø 95 x 1570
Boom cylinders - Number × diameter × stroke (mm)2 - ø 125 x ø 85 x 1320
Pilot pump typeGear pump, interactive sensing fuel saving pump system
Fuel Tank (L)340
Hydraulic Tank (L)180
Engine Oil changes (L)24
Coolant (L)35
Hydraulic System (L)270
Total transport length (mm)9510
Total transport width (mm)2800
Total transport height (mm)2990
Counterweight ground clearance (mm)1060
Minimum turning radius of front working device (mm)3770
Back end turning radius (mm)2830
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)7
Number of track plates (single side) (PCS)46
Maximum digging radius (mm)9930
Maximum digging depth (mm)6800
Maximum excavation height (mm)9730
Maximum unloading height (mm)6910
Maximum vertical digging depth (mm)6060
Maximum excavation radius of stop surface (mm)9760
see more

Overview

No.971072

Brand Name:

Hyundai

Model Number:

R215VS

Year:

2019

Location:

Jiangxi China
