Product Description
Engineered with dual variable plunger pumps delivering 2×222 L/min maximum flow, this 2010 Hyundai R215VSN excavator demonstrates superior hydraulic performance in the 21-ton class. Powered by a robust Cummins QSB7 engine generating 125kW at 1900 rpm, this machine combines proven reliability with impressive operational capabilities.
Key technical specifications include:
- Maximum digging reach of 9,720mm with 6,550mm depth capacity
- 0.83m³ bucket capacity optimized for medium-duty applications
- Advanced axial piston motors with automatic braking systems
- 70% climbing ability with dual-speed travel functionality
- 340L fuel tank supporting extended operational periods
Built during Hyundai's peak engineering period for this model series, the R215VSN features water-cooled 6-cylinder architecture with 6.7L displacement. Located in Hefei, Anhui Province, this unit represents exceptional value for contractors requiring dependable performance in demanding excavation projects. Comprehensive hydraulic system capacity of 270L ensures consistent operation under heavy loads.
| Specifications | Value |
|---|---|
| No. | 986998 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 19900 |
| Bucket capacity (m³) | 0.83 |
| Boom length (mm) | 5650 |
| Rod length (mm) | 2700 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins QSB7 |
| Rated power (kw/rpm) | 125/1900 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 107*124 |
| Maximum torque (N.m) | 67/1500 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Rotation speed (rpm) | 11.4 |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.9/3.8 |
| Rotary hydraulic motor type | Axial piston motor with automatic braking |
| Type of walking hydraulic motor | Two-speed axial plunger motor with brake valve and parking brake |
| Maximum flow of main pump (l/min) | 2*222 |
| Main pump type | Two variable plunger pump |
| Bucket cylinders - Number × diameter × stroke (mm) | 1*120*80*1120 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1*140*95*1570 |
| Boom cylinders - Number × diameter × stroke (mm) | 2*125*85*1320 |
| Pilot pump type | Gear pump |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 180 |
| Engine Oil changes (L) | 24 |
| Coolant (L) | 35 |
| Hydraulic System (L) | 270 |
| Total transport length (mm) | 9500 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2970 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum turning radius of front working device (mm) | 3470 |
| Back end turning radius (mm) | 2830 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 46 |
| Maximum digging radius (mm) | 9720 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9640 |
| Maximum unloading height (mm) | 6830 |
| Maximum vertical digging depth (mm) | 5920 |
| Maximum excavation radius of stop surface (mm) | 9550 |
