2016 Hyundai R485LVS

1/3
Used Hyundai R485LVS Excavator 2016 Model / 1
Used Hyundai R485LVS Excavator 2016 Model / 2
Used Hyundai R485LVS Excavator 2016 Model / 3

Product Description

There is currently a top-quality Hyundai R485LC-9 excavator equipped with a Dekker breaker, with a total working time of only 2,000 hours and in excellent condition. This device is equipped with a highly efficient and reliable Cummins QSL9-C324 engine, with a maximum power output of 244 kilowatts, ensuring strong power output and excellent fuel economy. In terms of the hydraulic system, the advanced Kawasaki K3V112DT main pump and the matching high-performance hydraulic motor are adopted, providing a stable and precise operation experience. The whole machine has a compact and sturdy structure, featuring a spacious and comfortable cab design. It is easy to operate and offers a wide field of vision. In addition, this R485LC-9 is specially equipped with a heavy-duty breaker of the Dekker brand, which is suitable for rock excavation and demolition operations in various complex working conditions, greatly improving work efficiency. Whether it's mining or urban construction, this excavator can handle it with ease and is your ideal choice to enhance productivity. It is expected that the equipment is well maintained and there is no obvious damage to its appearance. The specific usage situation may need further confirmation.

SpecificationsValue
No.978729
Tonnage (tons)48
Working weight (kg)48400
Bucket capacity (m³)2.2
Boom length (mm)6550
Rod length (mm)2900
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeCummins QSM11
Rated power (kw/rpm)266/1900
Cooling modewater-cooling
Cylinder diameter × stroke (mm)125 x 147.1
Number of cylinders (PCS)6
Displacement (L)10.8
Rotation speed (rpm)8.3
Climbing ability (%)70
Travel speed (km/h)4.7/2.9
Rotary hydraulic motor typeAxial plunger motor with automatic control
Maximum flow of main pump (l/min)2*370
Main pump typeTwo variable plunger pump
Bucket cylinders - Number × diameter × stroke (mm)1 - ø 160 x ø 110 x 1370
Bucket rod cylinders - Number × diameter × stroke (mm)1 - ø 190 x ø 130 x 1820
Boom cylinders - Number × diameter × stroke (mm)2 - ø 170 x ø 115 x 1570
Pilot pump typeGear pump
Fuel Tank (L)620
Hydraulic Tank (L)260
Engine Oil changes (L)38
Coolant (L)50
Hydraulic System (L)380
Total transport length (mm)11650
Total transport width (mm)3340
Total transport height (mm)3870
Full cab height (mm)3190
Counterweight ground clearance (mm)1295
Minimum turning radius of front working device (mm)4500
Back end turning radius (mm)3750
Onboard width (mm)2980
Track plate width (mm)600
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)9
Number of track plates (single side) (PCS)53
Maximum digging radius (mm)11040
Maximum digging depth (mm)6860
Maximum excavation height (mm)10440
Maximum unloading height (mm)7000
Maximum vertical digging depth (mm)5830
Maximum excavation radius of stop surface (mm)10820
see more

Overview

No.978729

Brand Name:

Hyundai

Model Number:

R485LVS

Year:

2016

Location:

Guangxi China
