2016 Hyundai XDL65

1/9
Used Hyundai XDL65 Excavator 2016 Model / 1
Used Hyundai XDL65 Excavator 2016 Model / 2
Used Hyundai XDL65 Excavator 2016 Model / 3
Used Hyundai XDL65 Excavator 2016 Model / 4
Used Hyundai XDL65 Excavator 2016 Model / 5
Used Hyundai XDL65 Excavator 2016 Model / 6
Used Hyundai XDL65 Excavator 2016 Model / 7
Used Hyundai XDL65 Excavator 2016 Model / 8
Used Hyundai XDL65 Excavator 2016 Model / 9

Product Description

"Modern 265-7 second-hand excavator This is a well-maintained and high-performance second-hand modern R265LC-7 excavator, suitable for various engineering operation requirements. Since its manufacture, this machine has accumulated a working time of 4,800 hours and is in the best working condition, ensuring its efficient and stable performance. In terms of the power system, it adopts the Cummins QSB6.7-C240 engine, which is powerful and has good fuel economy. The maximum output power can reach 169kW/228 horsepower. While ensuring strong digging force, it also significantly reduces fuel consumption costs. The hydraulic system adopts advanced negative flow control technology, making the operation more flexible and precise. It can handle both fine work and heavy-load excavation with ease. In addition, this machine is equipped with a reinforced chassis and extended tracks, ensuring excellent stability and passability even under harsh working conditions. It is particularly worth mentioning that the name "work vehicle" fully reflects its essence as a highly efficient construction equipment - it can not only meet the basic needs of daily earthwork excavation and loading, but also handle special tasks under complex terrain conditions. Now we

SpecificationsValue
No.971543
Tonnage (tons)26
Working weight (kg)25200
Bucket capacity (m³)1.08
Boom length (mm)5850
Rod length (mm)3050
Country of originJiangsu (Province)
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeCummins B5.9-C
Rated power (kw/rpm)133/2000
Cooling modewater-cooling
Cylinder diameter × stroke (mm)102 x 120
Number of cylinders (PCS)6
Displacement (L)5880
Ground specific pressure (Kpa)51
Rotation speed (rpm)12.6
Climbing ability (%)70/35 °
Bucket digging force (kN)178.5
Rod digging force (kN)118.7
Travel speed (km/h)3.5-5.5
Maximum flow of main pump (l/min)2 x 224
Traveling Hydraulic Circuit (Mpa)330
Rotary Hydraulic Circuit (Mpa)275
Hydraulic crushing pipeline is standardno
Main pump type2× variable axial piston pump + gear pump
Working Hydraulic Circuit (Mpa)330
Pilot Oil Circuit (MPa)35
Bucket cylinders - Number × diameter × stroke (mm)135 * 90 * 1185
Bucket rod cylinders - Number × diameter × stroke (mm)150 * 110 * 1620
Boom cylinders - Number × diameter × stroke (mm)140 * 95 * 1345
Fuel Tank (L)340
Hydraulic Tank (L)190
Engine Oil changes (L)24
Coolant (L)45
Hydraulic System (L)300
Total transport length (mm)9920
Total transport width (mm)3180
Total transport height (mm)3220
Full cab height (mm)2990
Counterweight ground clearance (mm)1115
Minimum ground clearance (mm)480
Back end turning radius (mm)2965
Total track length (mm)4640
Track gauge (mm)2580
Track plate width (mm)600
Total track width (mm)3180
Track ground length (mm)3830
Maximum digging radius (mm)10360
Maximum digging depth (mm)7000
Maximum excavation height (mm)9670
Maximum unloading height (mm)6630
Maximum vertical digging depth (mm)6150
Bulldozer lift or depth (mm)There is no
Dodging plate width × height (mm)There is no
Maximum excavation radius of stop surface (mm)10190
Maximum effective digging depth (mm)6380
see more

Overview

No.971543

Brand Name:

Hyundai

Model Number:

XDL65

Year:

2016

Location:

Zhejiang China
