Product Description
【 Premium Recommendation 】 Kato 1430V second-hand excavator, outstanding performance, ready to use right after purchase, go directly to the construction site! This second-hand Kato 1430V excavator has a working time of nearly 5,000 hours, yet its overall condition remains very good. This machine is equipped with an original imported Mitsubishi 6D22 engine, which is powerful, stable and reliable. Whether it is flat ground excavation or slope operation, it can handle it with ease. Meanwhile, this engine also features low fuel consumption and low noise, significantly reducing the usage cost and environmental impact. In terms of the hydraulic system, the Kato 1430V is equipped with an advanced negative flow control system, ensuring smoother and more precise movements and enhancing work efficiency. In addition, its unique rapid response mechanism enables operators to control the machine more flexibly, allowing them to handle even complex and changeable construction environments with ease. Most notably, after a comprehensive inspection and maintenance by our professional team, the condition of this excavator has reached the "performance exemption from inspection" standard - which means you can purchase it with confidence without worrying
| Specifications | Value |
|---|---|
| No. | 971118 |
| Tonnage (tons) | 31 |
| Working weight (kg) | 31000 |
| Bucket capacity (m³) | 1.1-1.8 |
| Boom length (mm) | 6480 |
| Rod length (mm) | 3140 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi 6M60-TLE3A |
| Rated power (kw/rpm) | 183/2150 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 118 x 115 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.54 |
| Ground specific pressure (Kpa) | 62 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 224 (Standard mode) /235 (Extra mode) |
| Rod digging force (kN) | 159 (Standard Mode) /166 (Power mode) |
| Travel speed (km/h) | 3.9/5.7 |
| Rotary hydraulic motor type | Constant piston motor |
| Type of walking hydraulic motor | Variable capacity piston motor |
| Maximum flow of main pump (l/min) | 307 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 32.9 |
| Main pump type | Variable capacity piston pump ×2+ gear pump |
| Working Hydraulic Circuit (Mpa) | 31.4 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-150 x 1230 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-170 x 1840 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-150 x 1450 |
| Fuel Tank (L) | 650 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 32 |
| Coolant (L) | 44 |
| Hydraulic System (L) | 404 |
| Total transport length (mm) | 11200 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3370 |
| Full cab height (mm) | 3020 |
| Counterweight ground clearance (mm) | 1130 |
| Minimum ground clearance (mm) | 500 |
| Minimum turning radius of front working device (mm) | 4640 |
| Back end turning radius (mm) | 3460 |
| Total track length (mm) | 4650 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 3760 |
| Maximum digging radius (mm) | 11180 |
| Maximum digging depth (mm) | 7450 |
| Maximum excavation height (mm) | 10330 |
| Maximum unloading height (mm) | 7280 |
| Maximum vertical digging depth (mm) | 5950 |
