Product Description
Built for endurance and proven in the field, this 2016 Kato HD308US excavator demonstrates exceptional longevity with its robust 8-ton frame and reliable ISUZU CC-4JG1 engine. After years of dependable service, this Japanese-engineered workhorse continues to deliver consistent performance with its 40.5kW power output and impressive 61.4kN bucket digging force.
Key specifications that define this proven machine:
- 8-ton operating weight with 0.28m³ bucket capacity
- Maximum digging depth of 4,120mm and reach of 6,470mm
- Dual variable capacity piston pumps for reliable hydraulic performance
- Compact transport dimensions: 6.3m × 2.3m × 2.6m
- Water-cooled 4-cylinder engine with 3.059L displacement
Currently located in Jiangxi Province, this HD308US represents Kato's commitment to building machines that withstand demanding conditions. With its established track record and durable construction, this excavator offers reliable productivity for contractors seeking proven equipment rather than untested alternatives.
| Specifications | Value |
|---|---|
| No. | 986664 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7600 |
| Bucket capacity (m³) | 0.28 |
| Boom length (mm) | 3830 |
| Rod length (mm) | 1620 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 95.4 x 107 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Ground specific pressure (Kpa) | 31.4 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 61.4 |
| Rod digging force (kN) | 42.2 |
| Travel speed (km/h) | 2.0/3.4/5.0 |
| Rotary hydraulic motor type | Constant piston motor |
| Type of walking hydraulic motor | Variable capacity piston motor |
| Maximum flow of main pump (l/min) | 77.7 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 31.4 |
| Main pump type | Variable capacity piston pump ×2+ gear pump |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-85 x 745 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-95 x 920 |
| Boom cylinders - Number × diameter × stroke (mm) | 1-105 x 960 |
| Fuel Tank (L) | 100 |
| Hydraulic Tank (L) | 48 |
| Engine Oil changes (L) | 9.6 |
| Coolant (L) | 11 |
| Hydraulic System (L) | 95 |
| Total transport length (mm) | 6300 |
| Total transport width (mm) | 2300 |
| Total transport height (mm) | 2600 |
| Full cab height (mm) | 2600 |
| Counterweight ground clearance (mm) | 740 |
| Minimum turning radius of front working device (mm) | 1630 |
| Back end turning radius (mm) | 1190 |
| Total track length (mm) | 2850 |
| Track gauge (mm) | 1850 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2300 |
| Track ground length (mm) | 2260 |
| Maximum digging radius (mm) | 6470 |
| Maximum digging depth (mm) | 4120 |
| Maximum excavation height (mm) | 7430 |
| Maximum unloading height (mm) | 5320 |
| Maximum vertical digging depth (mm) | 3620 |
| Bulldozer lift or depth (mm) | 430/330 |
| Dodging plate width × height (mm) | 2300 x 360 |
