Product Description
Built for demanding excavation work, this 2011 Kobelco SK200 delivers reliable performance with its proven Mitsubishi 6D34-TLU2D engine generating 110kW at 2000 rpm. Operating at 20 tons with superior hydraulic power, operators benefit from precise control through the dual variable displacement axial piston pump system and pilot gear pump configuration.
Exceptional stability comes from the optimized ground pressure distribution of 45/35 Kpa, while the reinforced undercarriage with 600/800mm track plates ensures confident operation across varied terrain. With 70% climbing capability and dual travel speeds (4.0/6.0 km/h), this machine handles challenging jobsite conditions effectively.
- Spacious operator cabin with enhanced visibility for safe, efficient operation
- Responsive joystick controls with 11 rpm rotation speed for precise positioning
- Robust bucket performance: 143kN digging force (157kN supercharged)
- Extended operational range with 340L fuel capacity
- Water-cooled turbocharged engine with intercooling for consistent power delivery
Currently located in Dali, Yunnan Province, this SK200 represents proven Kobelco engineering designed for professional contract
| Specifications | Value |
|---|---|
| No. | 986755 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20000 |
| Bucket capacity (m³) | 0.8 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi 6D34-TLU2D |
| Rated power (kw/rpm) | 110/2000 |
| Cooling mode | water-cooling |
| Working form | Water-cooled, four-stroke, six-cylinder, direct injection, turbocharged, built-in intercooling |
| Ground specific pressure (Kpa) | 45; 35 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 143; Supercharged state: 157 |
| Rod digging force (kN) | 97.1; Supercharged state: 107 |
| Travel speed (km/h) | 1 speed: 4.0 2 speed :6.0 |
| Main overflow set pressure (Mpa) | 34.3; Supercharged state: 37.8 |
| Main pump type | Double variable displacement axial piston pump pilot gear pump |
| Fuel Tank (L) | 340 |
| Track plate width (mm) | 600; 800 |
