| Specifications | Value |
|---|---|
| No. | 967454 |
| Tonnage (tons) | 33 |
| Working weight (kg) | 34500 |
| Bucket capacity (m³) | 1.5 |
| Rod length (mm) | 3300 |
| Bucket width (mm) | 1390 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Hino J08ETM-KSDL |
| Rated power (kw/rpm) | 209/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 998/1600 |
| Working form | Direct injection, water-cooled, four-stroke, turbocharged, built-in intercooling |
| Ground specific pressure (Kpa) | 70 |
| Rotation speed (rpm) | 10.0 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 165 |
| Maximum tractive force (kN) | 333 |
| Travel speed (km/h) | 5.6/3.3 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Axial piston pump motor ×1 |
| Type of walking hydraulic motor | Variable capacity axial piston motor x 2 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Fuel Tank (L) | 503 |
| Hydraulic Tank (L) | 245 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11300 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3430 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1190 |
| Minimum ground clearance (mm) | 500 |
| Onboard width (mm) | 2980 |
| Total track length (mm) | 4630 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3720 |
| Maximum digging radius (mm) | 11260 |
| Maximum digging depth (mm) | 7560 |
| Maximum excavation height (mm) | 10540 |
| Maximum unloading height (mm) | 7370 |
| Maximum vertical digging depth (mm) | 6480 |
| Maximum excavation radius of stop surface (mm) | 11060 |
Description
【 Second-hand Kobelco SK330-10 excavator 】 This second-hand Kobelco SK330-10 excavator is priced at only 230,000 RMB, offering an extremely high cost performance. It not only boasts powerful performance and excellent durability, but also features outstanding working efficiency. It is your ideal choice for various earthwork projects, mining or infrastructure construction. 【 Working Hours This excavator has accumulated 8,000 hours of operation and is in a medium service life. It is in good overall condition and well-maintained, capable of meeting the demands of long-term high-intensity operations. Its core components such as the engine and hydraulic pump have all undergone strict testing to ensure there are no potential faults and that it can operate stably. "Power System This device is equipped with a high-performance Isuzu 6BG1 inline six-cylinder water-cooled turbocharged diesel engine, with a maximum output power of up to 202kW at 1900rpm. It has abundant torque and can maintain strong power output even under harsh working conditions. Meanwhile, the efficient fuel injection system leads to lower fuel consumption and better economy. "Hydraulic System By adopting advanced negative flow control technology and integrating with an int
