2016 Kobelco SK380XD-10






| Specifications | Value |
|---|---|
| No. | 966020 |
| Tonnage (tons) | 38 |
| Working weight (kg) | 38500 |
| Bucket capacity (m³) | 1.9 |
| Boom length (mm) | 2600 |
| Rod length (mm) | 6500 |
| Bucket width (mm) | 1740 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Hino J08ETM-KSDL |
| Rated power (kw/rpm) | 197/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 968/1600 |
| Working form | Direct injection, four stroke, turbocharged, built-in intercooling |
| Ground specific pressure (Kpa) | 72 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70 (35°) |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 207 |
| Maximum tractive force (kN) | 331 |
| Travel speed (km/h) | 5.6/3.3 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Axial piston pump motor (1) |
| Type of walking hydraulic motor | Variable capacity axial piston motors (2) |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Fuel Tank (L) | 503 |
| Hydraulic Tank (L) | 245 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11380 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3710 |
| Full cab height (mm) | 3230 |
| Counterweight ground clearance (mm) | 1210 |
| Minimum ground clearance (mm) | 515 |
| Minimum turning radius of front working device (mm) | 4460 |
| Total track length (mm) | 4980 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4050 |
| Maximum digging radius (mm) | 10610 |
| Maximum digging depth (mm) | 6840 |
| Maximum excavation height (mm) | 10230 |
| Maximum unloading height (mm) | 7070 |
| Maximum vertical digging depth (mm) | 5700 |
| Maximum excavation radius of stop surface (mm) | 10400 |
Description
"Premium second-hand Kobelco 380-10 excavator Dear customer, hello! We currently have a second-hand Kobelco 380-10 excavator with excellent performance and in good condition for sale. Since this machine was put into use in 2015, its total working hours have only been 4,500 hours, far lower than the average service life of similar equipment. Therefore, its core components still maintain an excellent working condition. In terms of power, this excavator is equipped with a high-performance engine from the original factory, featuring strong power output and smooth operation characteristics. Even in the face of complex and diverse working environments, it can handle them with ease and ensure the efficient completion of tasks. Meanwhile, the advanced fuel management system effectively reduces the fuel consumption rate, saving users a large amount of operating costs. The hydraulic system is one of the key factors in evaluating the quality of an excavator. This Kobelco 380-10 is equipped with high-quality hydraulic pumps and motors imported from Japan, featuring rapid response and precise control. It performs exceptionally well in both excavation and loading operations. More importantly, it is equipped with an enhanced heat dissipation devic
Overview
No.966020
Brand Name:
KobelcoModel Number:
SK380XD-10Year:
2016
Location:
Zhejiang China
