Product Description
This 2019 Kobelco 75 excavator, with its outstanding performance and excellent working condition, has become a highly anticipated second-hand device in the market. According to the records, the device was only used for a small number of hours (the exact working time needs to be confirmed), and the overall condition of the vehicle was maintained very well, almost comparable to that of a new car. It is equipped with a high-performance engine (model to be confirmed), with an expected power of 40 to 50 kilowatts, ensuring strong digging force and efficient operation capacity. In terms of the hydraulic system, this Kobelco 75 is equipped with an advanced combination of a hydraulic pump and a hydraulic motor, which not only ensures smooth operation and response speed but also significantly improves fuel economy. Its outstanding sealing technology enables the entire hydraulic system to maintain a good condition even after long-term operation, truly achieving the high standard requirement of "no oil leakage from large components". In addition, this excavator also features a spacious and comfortable cab, an easy-to-operate control panel, and a sturdy and durable chassis structure, among many other advantages. Whether in terms of power output
| Specifications | Value |
|---|---|
| No. | 977559 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7000(approx) |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AU4LE2X |
| Rated power (kw/rpm) | 41/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 85 x 96 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.179 |
| Rotary hydraulic motor type | Axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 27.5 |
| Rotary Hydraulic Circuit (Mpa) | 14.5 |
| Control Hydraulic Circuit (Mpa) | 3.5 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 72 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 8.5 |
| Hydraulic System (L) | 120 |
| Total transport height (mm) | 2630 |
| Full cab height (mm) | 2630 |
| Minimum turning radius of front working device (mm) | 1760 |
| Back end turning radius (mm) | 1290 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4160 |
| Maximum excavation height (mm) | 7390 |
| Maximum unloading height (mm) | 5330 |
| Maximum vertical digging depth (mm) | 3450 |
| Maximum excavation radius of stop surface (mm) | 6300 |
| Maximum effective digging depth (mm) | 3800 |
| Travel speed (km/h) | 2.8/5.3 |
