| Specifications | Value |
|---|---|
| No. | 967326 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 23,900-24,850 |
| Bucket capacity (m³) | 1.45 |
| Boom length (mm) | 5900 |
| Rod length (mm) | 2000/2500/3000 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins QSB 6.7 |
| Rated power (kw/rpm) | 125/1800 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 107 * 124 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | 4-stroke diesel engine common rail, turbocharged |
| Rotation speed (rpm) | 0-11.3 |
| Bucket digging force (kN) | 157 |
| Maximum tractive force (kN) | 228 |
| Travel speed (km/h) | 3.0/5.0 |
| Turning torque (Nm) | 73.3 |
| Maximum flow of main pump (l/min) | 2 x 216 |
| Main pump type | In-line double swash plate variable pump |
| Fuel Tank (L) | 580 |
| Hydraulic Tank (L) | 100 |
| Hydraulic System (L) | 300 |
| Maximum digging depth (mm) | 6950 |
| Maximum excavation height (mm) | 9850 |
| Maximum unloading height (mm) | 6950 |
| Maximum excavation radius of stop surface (mm) | 10100 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8/9 |
Description
【 Premium Recommendation 】 Second-hand Liebherr 924 excavator from 2018, with outstanding performance and no inspection required! This second-hand Liebherr 924 excavator from 2018 has only accumulated 3,500 hours of working time since it was put into use, which is far below the average service life of similar equipment and is in the best working condition. It is equipped with a high-performance diesel engine independently developed by Liebherr, which is powerful and has excellent fuel economy, and can easily meet the operation requirements under various complex working conditions. This engine features outstanding durability and reliability, maintaining efficient operation even in harsh environments. In terms of the hydraulic system, the 924 is equipped with an advanced closed load-sensitive hydraulic system, ensuring smooth and precise operation. Whether it is excavation, loading or crushing operations, rapid response and precise control can be achieved, greatly improving work efficiency. In addition, its unique energy-saving mode can further reduce fuel consumption without affecting performance, saving users more operating costs. Most notably, this excavator has undergone strict quality inspection. All key components are in good co
