HOME>>Brands>>Sany SY215C-9

2013 Sany SY215C-9

1/9
Used Sany SY215C-9 Excavator 2013 Model / 1
Used Sany SY215C-9 Excavator 2013 Model / 2
Used Sany SY215C-9 Excavator 2013 Model / 3
Used Sany SY215C-9 Excavator 2013 Model / 4
Used Sany SY215C-9 Excavator 2013 Model / 5
Used Sany SY215C-9 Excavator 2013 Model / 6
Used Sany SY215C-9 Excavator 2013 Model / 7
Used Sany SY215C-9 Excavator 2013 Model / 8
Used Sany SY215C-9 Excavator 2013 Model / 9

Product Description

There is currently a second-hand Sany SY215-9 excavator produced in 2013. The total working time is moderate, ensuring the stability and reliability of the equipment. This excavator is equipped with an original imported engine, model Isuzu 4HK1X, with a rated power of 110kW (approximately 150 horsepower). It is powerful and fuel-efficient, making it suitable for various earthwork operation requirements. The hydraulic system is highly efficient, equipped with well-known brand hydraulic pumps and motors, which can provide stable and abundant power output, ensuring construction efficiency while reducing maintenance costs. As an excavator specially designed for earthwork projects, this SY215-9 features an excellent chassis structure. Even after long-term use, it remains in good condition with no obvious signs of wear, demonstrating its sturdiness and durability. In addition, the entire machine has excellent sealing performance. The large components do not leak oil, and the circuit system operates normally without any arm drop phenomenon, further ensuring the safety and stability of operation. This excavator not only has excellent performance but also a reasonable price. Currently, it is priced at only 98,000 RMB and can be picked up imme

SpecificationsValue
No.973481
Tonnage (tons)21
Working weight (kg)21800
Bucket capacity (m³)0.93 (0.8~1.2)
Country of originShanghai
powerTraditional power
manufacturerMade in China
bucketbackhoe
Rated power (kw/rpm)114/2050
Cooling modewater-cooling
Ground specific pressure (Kpa)46.5
Rotation speed (rpm)11
Climbing ability (%)70/35 °
Bucket digging force (kN)138
Rod digging force (kN)103
Travel speed (km/h)5.4/3.3
Main overflow set pressure (Mpa)34.3
Maximum flow of main pump (l/min)2 x 210
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)25.5
Control Hydraulic Circuit (Mpa)3.9
Hydraulic crushing pipeline is standardno
Total transport length (mm)9680
Total transport width (mm)2980
Total transport height (mm)3440
Full cab height (mm)2990
Minimum ground clearance (mm)440
Minimum turning radius of front working device (mm)3595
Back end turning radius (mm)2890
Onboard width (mm)2710
Total track length (mm)4250
Track gauge (mm)2380
Track plate width (mm)600 (800/700 optional)
Total track width (mm)2980
Track ground length (mm)3445
Maximum digging radius (mm)9950
Maximum digging depth (mm)6600
Maximum excavation height (mm)9570
Maximum unloading height (mm)6700
Maximum vertical digging depth (mm)5800
Bulldozer lift or depth (mm)There is no
Dodging plate width × height (mm)There is no
Maximum excavation radius of stop surface (mm)9885
see more

Overview

No.973481

Brand Name:

Sany

Model Number:

SY215C-9

Year:

2013

Location:

Jiangsu China
