Product Description
There is currently a Sany SY215C-9 excavator produced at the end of 2015, which has been in operation for just over 10 hours and is almost in brand new condition. This excavator is equipped with a high-performance Isuzu 4HK1 engine, with a maximum power output of 118kW, ensuring strong power output and efficient operation capability. Its advanced hydraulic system is equipped with a high-flow main pump and high-quality hydraulic motors, which can achieve a precise and smooth operation experience, while ensuring the stability and reliability of the equipment under various complex working conditions. One of the highlights of this model is the adoption of a reinforced chassis design, which not only enhances the overall load capacity and durability of the machine but also optimizes its driving performance, ensuring good passability and stability even on uneven ground. In addition, the spacious and comfortable cab is equipped with humanized facilities such as air conditioning for both heating and cooling, and shock-absorbing seats, providing an excellent working environment for the operator. Considering its extremely low service life and the consistently good reputation of the Sany brand, this SY215C-9 excavator is undoubtedly a highly cos
| Specifications | Value |
|---|---|
| No. | 976289 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21800 |
| Bucket capacity (m³) | 0.93 (0.8~1.2) |
| Country of origin | Shanghai |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 114/2050 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 46.5 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 2 x 210 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 2990 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3595 |
| Back end turning radius (mm) | 2890 |
| Onboard width (mm) | 2710 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 (800/700 optional) |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3445 |
| Maximum digging radius (mm) | 9950 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9570 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 5800 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 9885 |
