Product Description
Built for demanding construction environments, this 2018 Sany SY225C excavator delivers reliable 23-ton performance with exceptional operator control. Powered by a robust 4M50 engine producing 118kW at 2000 RPM, this machine combines proven hydraulic systems with superior cabin design for maximum productivity.
Operators benefit from enhanced visibility and ergonomic controls within the spacious cab, while the machine's 47.4 kPa ground pressure ensures stable operation across varied terrain. With 138kN bucket digging force and 103kN rod digging force, this excavator handles heavy-duty excavation tasks efficiently.
- 23-ton working weight with 1.2m³ bucket capacity
- 10.28m maximum digging radius, 6.6m digging depth
- 340L fuel tank for extended operation cycles
- 70% climbing ability on steep grades
- Dual-speed travel system (5.4/3.3 km/h)
- Located in Hunan Province, China
This well-maintained unit represents solid value for contractors requiring dependable excavation capabilities with proven Sany engineering and straightforward maintenance protocols.
| Specifications | Value |
|---|---|
| No. | 981248 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 22300 |
| Bucket capacity (m³) | 1.1~1.2(1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 2 |
| Coolant (L) | 30.9 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Counterweight ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
