| Specifications | Value |
|---|---|
| No. | 963974 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 31500 |
| Bucket capacity (m³) | 1.65~2.0(1.65) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu GH-6HK1 |
| Rated power (kw/rpm) | 212/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 1080/1500 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Ground specific pressure (Kpa) | 62.3 |
| Rotation speed (rpm) | 9.0 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 204 |
| Rod digging force (kN) | 153 |
| Travel speed (km/h) | 5.4/3.2 |
| Fuel Tank (L) | 540 |
| Hydraulic Tank (L) | 380 |
| Engine Oil changes (L) | 2*4.0 |
| Coolant (L) | 35 |
| Total transport length (mm) | 10667 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3470 |
| Full cab height (mm) | 3280 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4000 |
| Back end turning radius (mm) | 3315 |
| Onboard width (mm) | 3175 |
| Total track length (mm) | 4840 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3916 |
| Maximum height at minimum turning radius (mm) | 8405 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10870 |
| Maximum digging depth (mm) | 6815 |
| Maximum excavation height (mm) | 10497 |
| Maximum unloading height (mm) | 7359 |
| Maximum vertical digging depth (mm) | 6170 |
Description
【 Premium Recommendation 】 The new eight-wheel pure Sany 305H-9 excavator is now in nearly new condition, with outstanding overall performance, making it an ideal choice for your engineering operations. Since its manufacture, this excavator has been in operation for only 1,200 hours, which is far shorter than the average usage time of the same model, ensuring the high efficiency and durability of the equipment. In terms of the power system, this machine is equipped with an original imported engine from Sany, which features strong power output and smooth operation characteristics. Even in complex and harsh working environments, it can maintain stable and efficient performance. In addition, this engine also features excellent fuel economy, effectively reducing operating costs. The hydraulic system adopts advanced load sensing technology, which can automatically adjust the oil pressure and flow rate according to the actual working conditions. This not only improves the operational accuracy and flexibility but also significantly extends the service life of the hydraulic components. Whether it is tasks such as excavation, loading or land leveling, they can all be handled with ease, demonstrating outstanding work efficiency. It is worth m
