| Specifications | Value |
|---|---|
| No. | 964540 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 36000 |
| Bucket capacity (m³) | 1.6~2.32 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | GH-6HK1XKSC |
| Rated power (kw/rpm) | 212/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 1080/1500 |
| Displacement (L) | 7.79 |
| Ground specific pressure (Kpa) | 65 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 235 |
| Rod digging force (kN) | 180 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 690 |
| Hydraulic Tank (L) | 380 |
| Engine Oil changes (L) | 36 |
| Total transport length (mm) | 11530 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3545 |
| Full cab height (mm) | 3320 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4495 |
| Back end turning radius (mm) | 3560 |
| Onboard width (mm) | 3150 |
| Total track length (mm) | 5065 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4140 |
| Maximum height at minimum turning radius (mm) | 8600 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10780 |
| Maximum digging depth (mm) | 7050 |
| Maximum excavation height (mm) | 9890 |
| Maximum unloading height (mm) | 6920 |
| Maximum vertical digging depth (mm) | 3970 |
Description
【 Premium Recommendation 】 Top-quality original Sany 365-9 excavator, with no alterations to the entire vehicle's original version, outstanding performance, and quality guaranteed. This excavator has a working time of only 2,000 hours, which is far shorter than the average service life of similar equipment, ensuring its superior mechanical condition and long-term durability. The power system adopts high-quality engines, which are stable in operation, low in noise and economical in fuel consumption. Even in harsh environments, it can maintain efficient operation. The hydraulic system has been meticulously designed and optimized, featuring rapid response and precise control. It can handle operations such as excavation, loading, and crushing with ease, meeting the demands of various complex working conditions. It is particularly worth mentioning that the major components of this excavator (such as the main pump, main valve and other key parts) have not been disassembled or repaired in any way, maintaining the best condition at the factory and significantly reducing the later maintenance costs. In addition, the original vehicle slats are intact, with a neat and beautiful appearance. The internal structure is also dry and clean, and there
