| Specifications | Value |
|---|---|
| No. | 970888 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20600 |
| Bucket capacity (m³) | 0.9-1.0 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 117.3/1800 |
| Cylinder diameter × stroke (mm) | 115 x 125 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 5.193 |
| Ground specific pressure (Kpa) | 45 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 142 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 3.4/5.6 |
| Type of walking hydraulic motor | Variable axial piston motor |
| Maximum flow of main pump (l/min) | 422 |
| Main pump type | |
| Bucket cylinders - Number × diameter × stroke (mm) | |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 140 x 1460 |
| Boom cylinders - Number × diameter × stroke (mm) | |
| Fuel Tank (L) | 410 |
| Hydraulic Tank (L) | 147 |
| Engine Oil changes (L) | 23.1 |
| Coolant (L) | 26 |
| Hydraulic System (L) | 240 |
| Total transport length (mm) | 9400 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2970 |
| Counterweight ground clearance (mm) | 1040 |
| Minimum ground clearance (mm) | 460 |
| Minimum turning radius of front working device (mm) | 3600 |
| Back end turning radius (mm) | 2720 |
| Total track length (mm) | 4180 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3370 |
| Maximum digging radius (mm) | 9900 |
| Maximum digging depth (mm) | 6650 |
| Maximum excavation height (mm) | 9610 |
| Maximum unloading height (mm) | 6810 |
| Maximum vertical digging depth (mm) | 5960 |
Description
【 Premium Recommendation 】 Sumitomo 210-5 second-hand excavator, first-hand stock, construction site work vehicle, no inspection for vehicle condition and performance, tens of thousands of yuan, customers come! This second-hand Sumitomo 210-5 excavator is a first-hand stock carefully selected by us. It has been used in regular construction sites since purchase, with a working time of only 3,800 hours. The usage frequency is moderate and it is well maintained. The overall condition of the vehicle is excellent. In terms of the power system, this machine is equipped with an original imported high-quality engine, which is powerful, stable and reliable. It can maintain efficient operation even under harsh working conditions. The hydraulic system adopts an advanced closed-loop design, ensuring precise control and smooth operation during the excavation process. Whether it is excavation, loading or crushing operations, it can handle them with ease. In addition, this machine is also equipped with a number of intelligent auxiliary functions, such as automatic idle speed adjustment and energy-saving mode, which further enhance work efficiency and reduce fuel consumption. As a construction site work vehicle, Sumitomo 210-5 has won the trust and
