2021 Sumitomo SH80-6

1/6
Used Sumitomo SH80-6 Excavator 2021 Model / 1
Used Sumitomo SH80-6 Excavator 2021 Model / 2
Used Sumitomo SH80-6 Excavator 2021 Model / 3
Used Sumitomo SH80-6 Excavator 2021 Model / 4
Used Sumitomo SH80-6 Excavator 2021 Model / 5
Used Sumitomo SH80-6 Excavator 2021 Model / 6

Product Description

【 Premium Recommendation 】 Multiple top-quality 2021 Sumitomo SH480-6 excavators We have carefully selected multiple second-hand Sumitomo SH480-6 excavators from 2021 for you. Each one is a high-quality device that has undergone strict screening and comprehensive testing. The working hours of these excavators are all within 2,000 hours, ensuring that what you purchase is not only cost-effective equipment but also high-quality machinery with stable performance and a long service life. The Sumitomo SH480-6 is equipped with an advanced power system - the Cummins QSL9-C325 engine. This engine is renowned for its powerful output and smooth operation. While ensuring efficient operation, it can also effectively reduce fuel consumption and achieve the goal of energy conservation and emission reduction. In addition, it is also equipped with the HIOS III hydraulic system independently developed by Sumitomo. This system not only has a fast response speed and high operational flexibility, but also can automatically adjust the power output according to different working conditions, thereby improving work efficiency and extending the machine's service life. As a large excavator, the SH480-6 features a spacious and comfortable cab design, equipped

SpecificationsValue
No.971733
Tonnage (tons)8
Working weight (kg)7460
Bucket capacity (m³)0.38
Rod length (mm)1690
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeIsuzu AU-4LE2X
Rated power (kw/rpm)40/2000
Displacement (L)2.179
Rotation speed (rpm)9.9
Climbing ability (%)
Bucket digging force (kN)56.4
Rod digging force (kN)39.3
Travel speed (km/h)5.1/3.2
Main overflow set pressure (Mpa)29.4
Type of walking hydraulic motor
Main pump type
Working Hydraulic Circuit (Mpa)29.4
Fuel Tank (L)120
Hydraulic Tank (L)51
Hydraulic System (L)96
Total transport length (mm)6090
Total transport width (mm)2320
Total transport height (mm)2750
Counterweight ground clearance (mm)750
Minimum turning radius of front working device (mm)1980
Back end turning radius (mm)1750
Total track length (mm)2845
Track plate width (mm)450
Total track width (mm)2320
Track ground length (mm)2210
Maximum digging radius (mm)6460
Maximum digging depth (mm)4050
Maximum excavation height (mm)6950
Maximum unloading height (mm)4890
see more

Overview

No.971733

Brand Name:

Sumitomo

Model Number:

SH80-6

Year:

2021

Location:

Zhejiang China
