Product Description
Engineered with Volvo's renowned D7E turbocharged engine delivering 169kW at 1800rpm, this 2014 EC300D excavator represents industrial-grade reliability in the 30-ton class. Advanced hydraulic systems feature dual 263 l/min main pumps operating at 33.3/36.3 MPa working pressure, providing exceptional digging force and precise control across demanding applications.
Built on proven EC300D architecture, this machine combines a robust 7.1L displacement engine with sophisticated hydraulic circuits optimized for heavy construction work. Key performance specifications include:
- Maximum digging reach: 10,190mm with 6,850mm depth capability
- 1.4m³ bucket capacity with 247kN maximum tractive force
- 10.7rpm rotation speed for efficient positioning
- 35° climbing ability for challenging terrain access
Located in Shanghai, this EC300D maintains Volvo's engineering standards with comprehensive hydraulic integration, 470L fuel capacity for extended operation cycles, and transport dimensions of 10,640 x 3,190 x 3,090mm. Professional maintenance records available upon request.
| Specifications | Value |
|---|---|
| No. | 982988 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 30040 |
| Bucket capacity (m³) | 1.4 |
| Boom length (mm) | 6430 |
| Rod length (mm) | 3710 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | D7E |
| Rated power (kw/rpm) | 169/1800 |
| Cylinder diameter × stroke (mm) | 108 x 130 |
| Maximum torque (N.m) | 1080/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.1 |
| Working form | Turbocharged, 4-stroke, water-cooled, direct injection |
| Rotation speed (rpm) | 10.7 |
| Climbing ability (%) | 35 ° |
| Maximum tractive force (kN) | 247 |
| Travel speed (km/h) | 3.4/5.4 |
| Turning torque (Nm) | 110.9 |
| Maximum flow of main pump (l/min) | 2 x 263 |
| Traveling Hydraulic Circuit (Mpa) | 36.3 |
| Rotary Hydraulic Circuit (Mpa) | 27.9 |
| Working Hydraulic Circuit (Mpa) | 33.3/36.3 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 140 x 1140 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 150 x 1745 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 140 x 1480 |
| Fuel Tank (L) | 470 |
| Hydraulic Tank (L) | 195 |
| Coolant (L) | 41 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 10640 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3090 |
| Full cab height (mm) | 3090 |
| Counterweight ground clearance (mm) | 1135 |
| Minimum ground clearance (mm) | 480 |
| Onboard width (mm) | 890 |
| Total track length (mm) | 4870 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 10190 |
| Maximum digging depth (mm) | 6850 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6670 |
| Maximum vertical digging depth (mm) | 5730 |
| Maximum excavation radius of stop surface (mm) | 9980 |
| Maximum effective digging depth (mm) | 6610 |
