| Specifications | Value |
|---|---|
| No. | 969928 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
Description
This second-hand XCMG XE135 excavator from 2014 is highly favored in the market for its outstanding performance and durability. This equipment adopts a brand-new chassis design, which not only enhances the overall stability and operational comfort of the machine but also significantly extends its service life. Its cumulative working time is 7,500 hours. For a medium-sized excavator, this usage period is within a very ideal range, indicating that it still has a long service life. In terms of power, this XCMG XE135 is equipped with a highly efficient and energy-saving engine, which can provide strong and smooth power output. Even in complex or harsh working environments, it can maintain good working efficiency. Meanwhile, the advanced fuel management system leads to lower fuel consumption and effective control of operating costs. The hydraulic system is a major highlight of this machine. It adopts core components from internationally renowned brands, ensuring rapid and accurate response to actions and uniform and smooth force transmission. Whether it is digging, loading or other heavy tasks, it can handle them with ease, demonstrating excellent operational flexibility and high-precision control capabilities. In addition, considering t
