| Specifications | Value |
|---|---|
| No. | 964779 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1640 |
| Bucket capacity (m³) | 0.044 |
| Boom length (mm) | 1690 |
| Rod length (mm) | 1100 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 3TNV82A |
| Rated power (kw/rpm) | 16.5/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.33 |
| Ground specific pressure (Kpa) | 23.8 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 13.9 |
| Rod digging force (kN) | 8.8 |
| Travel speed (km/h) | 4.4/2.4 |
| Main overflow set pressure (Mpa) | 24 |
| Maximum flow of main pump (l/min) | 2*19.8+14.1 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 18 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Japan Fujikoshi |
| Pilot pump flow (L/min) | 3.3 |
| Fuel Tank (L) | 20 |
| Hydraulic Tank (L) | 29 |
| Engine Oil changes (L) | 5.5 |
| Total transport length (mm) | 3760 |
| Total transport width (mm) | 1080 |
| Total transport height (mm) | 2400 |
| Counterweight ground clearance (mm) | 472 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1675 |
| Back end turning radius (mm) | 1190 |
| Track gauge (mm) | 850 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1217 |
| Maximum digging radius (mm) | 3915 |
| Maximum digging depth (mm) | 2320 |
| Maximum excavation height (mm) | 3615 |
| Maximum unloading height (mm) | 2480 |
| Maximum vertical digging depth (mm) | 1520 |
| Dodging plate width × height (mm) | 1080*225 |
Description
XCMG XE15 second-hand excavator, the best choice for cost performance We are selling a second-hand XCMG XE15 excavator purchased in 2020. Since its purchase, this equipment has been meticulously maintained and has accumulated a working time of only 1,200 hours, which is far lower than the average usage time of similar equipment. Both in appearance and performance, it remains in an excellent state, making it a capable assistant in your construction projects. "Power System It is equipped with a well-known brand engine, which is powerful and has good fuel economy. Even under harsh working conditions, it can ensure efficient operation. After professional testing, all the indicators of the engine meet the standards. It operates smoothly without noise, starts quickly, responds sensitively, and can easily handle various complex terrains and operation requirements. "Hydraulic System Equipped with advanced negative flow control technology, it ensures more precise and smooth operation of the entire machine. Both the hydraulic pump and the motor are original imported components, ensuring reliable quality and durability. The entire hydraulic circuit is rationally designed, reducing energy loss, improving work efficiency and lowering the failure
