Product Description
【 Premium Recommendation 】 20-year-old XCMG XE135 second-hand excavator, with outstanding performance and quality guaranteed! This XCMG XE135 excavator was manufactured in 2020 and has been in operation for only 2,500 hours, almost in brand new condition. The overall appearance of the machine shows no obvious wear and tear, the chassis structure is intact, and the paint is as bright as new. It fully meets your expectations for high-quality second-hand machinery. In terms of the power system, this machine is equipped with a Yanmar engine that has been well-tested in the market. It is powerful and has high fuel economy. Whether it is flat ground work or complex terrain construction, it can handle it with ease. More importantly, this engine runs smoothly and with low noise, providing the operator with a more comfortable driving experience. The hydraulic system adopts advanced load-sensitive technology, ensuring precise control and efficient operation under various working conditions. Whether it is the depth of excavation or the speed of improvement, it has reached the leading level in the industry, greatly enhancing work efficiency. In addition, this equipment is also equipped with a spacious and comfortable cab, offering a wide field
| Specifications | Value |
|---|---|
| No. | 971218 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1640 |
| Bucket capacity (m³) | 0.044 |
| Boom length (mm) | 1690 |
| Rod length (mm) | 1100 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 3TNV82A |
| Rated power (kw/rpm) | 16.5/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.33 |
| Ground specific pressure (Kpa) | 23.8 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 13.9 |
| Rod digging force (kN) | 8.8 |
| Travel speed (km/h) | 4.4/2.4 |
| Main overflow set pressure (Mpa) | 24 |
| Maximum flow of main pump (l/min) | 2*19.8+14.1 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 18 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Japan Fujikoshi |
| Pilot pump flow (L/min) | 3.3 |
| Fuel Tank (L) | 20 |
| Hydraulic Tank (L) | 29 |
| Engine Oil changes (L) | 5.5 |
| Total transport length (mm) | 3760 |
| Total transport width (mm) | 1080 |
| Total transport height (mm) | 2400 |
| Counterweight ground clearance (mm) | 472 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1675 |
| Back end turning radius (mm) | 1190 |
| Track gauge (mm) | 850 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1217 |
| Maximum digging radius (mm) | 3915 |
| Maximum digging depth (mm) | 2320 |
| Maximum excavation height (mm) | 3615 |
| Maximum unloading height (mm) | 2480 |
| Maximum vertical digging depth (mm) | 1520 |
| Dodging plate width × height (mm) | 1080*225 |
