Product Description
【 Premium Recommendation 】2023 Premium XCMG XE15 second-hand excavator, only 50,000 yuan! This small excavator is not only affordable but also has excellent performance, making it an ideal choice for your construction work. This machine has a working time of only 2,300 hours, almost in the condition of a nearly new car. It is well maintained, with a clean appearance and no obvious damage. In terms of the power system, this XCMG XE15 is equipped with an efficient and energy-saving engine, ensuring a perfect balance between strong power output and low fuel consumption. Whether it is urban road construction or rural farmland renovation, it can easily meet the operation demands under various complex working conditions. More importantly, this engine also pays special attention to environmental protection design, meeting the latest national emission standards, making your investment more green and sustainable. The hydraulic system adopts advanced load-sensitive technology, which can automatically adjust the flow and pressure according to the actual operation conditions, thus achieving precise control and greatly improving work efficiency. In addition, the entire set of hydraulic components are all from well-known brand suppliers, ensuring
| Specifications | Value |
|---|---|
| No. | 972340 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1640 |
| Bucket capacity (m³) | 0.044 |
| Boom length (mm) | 1690 |
| Rod length (mm) | 1100 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 3TNV82A |
| Rated power (kw/rpm) | 16.5/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.33 |
| Ground specific pressure (Kpa) | 23.8 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 13.9 |
| Rod digging force (kN) | 8.8 |
| Travel speed (km/h) | 4.4/2.4 |
| Main overflow set pressure (Mpa) | 24 |
| Maximum flow of main pump (l/min) | 2*19.8+14.1 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 18 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Japan Fujikoshi |
| Pilot pump flow (L/min) | 3.3 |
| Fuel Tank (L) | 20 |
| Hydraulic Tank (L) | 29 |
| Engine Oil changes (L) | 5.5 |
| Total transport length (mm) | 3760 |
| Total transport width (mm) | 1080 |
| Total transport height (mm) | 2400 |
| Counterweight ground clearance (mm) | 472 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1675 |
| Back end turning radius (mm) | 1190 |
| Track gauge (mm) | 850 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1217 |
| Maximum digging radius (mm) | 3915 |
| Maximum digging depth (mm) | 2320 |
| Maximum excavation height (mm) | 3615 |
| Maximum unloading height (mm) | 2480 |
| Maximum vertical digging depth (mm) | 1520 |
| Dodging plate width × height (mm) | 1080*225 |
