Product Description
There is currently a second-hand XCMG XE135 excavator produced in 2013, with a working time of only over 150,000 hours. It is stable and reliable in performance and is an ideal choice for your engineering operations. This equipment is equipped with the highly efficient and energy-saving Weichai WP4G158E33 engine, with a rated power of 96kW, ensuring a perfect combination of strong power output and fuel economy. Even in complex and changeable construction environments, it can easily handle various challenges. It is equipped with an advanced hydraulic system, including high-quality Kawasaki main pumps and rotary motors, ensuring smooth operation and rapid response of the entire machine. Whether it is excavation, loading or crushing operations, it can perform well. In addition, the XCMG XE135 also adopts an optimally designed working device, enhancing structural strength and durability, and effectively extending the machine's service life. As a second-hand excavator with extremely high cost performance, it not only has outstanding performance but also a reasonable price. Currently, it is available in local stock. Welcome friends in need to come for a test drive and experience! It is expected that this model of excavator will continue to
| Specifications | Value |
|---|---|
| No. | 978001 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1640 |
| Bucket capacity (m³) | 0.044 |
| Boom length (mm) | 1690 |
| Rod length (mm) | 1100 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 3TNV82A |
| Rated power (kw/rpm) | 16.5/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.33 |
| Ground specific pressure (Kpa) | 23.8 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 13.9 |
| Rod digging force (kN) | 8.8 |
| Travel speed (km/h) | 4.4/2.4 |
| Main overflow set pressure (Mpa) | 24 |
| Maximum flow of main pump (l/min) | 2*19.8+14.1 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 18 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Japan Fujikoshi |
| Pilot pump flow (L/min) | 3.3 |
| Fuel Tank (L) | 20 |
| Hydraulic Tank (L) | 29 |
| Engine Oil changes (L) | 5.5 |
| Total transport length (mm) | 3760 |
| Total transport width (mm) | 1080 |
| Total transport height (mm) | 2400 |
| Counterweight ground clearance (mm) | 472 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1675 |
| Back end turning radius (mm) | 1190 |
| Track gauge (mm) | 850 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1217 |
| Maximum digging radius (mm) | 3915 |
| Maximum digging depth (mm) | 2320 |
| Maximum excavation height (mm) | 3615 |
| Maximum unloading height (mm) | 2480 |
| Maximum vertical digging depth (mm) | 1520 |
| Dodging plate width × height (mm) | 1080*225 |
