| Specifications | Value |
|---|---|
| No. | 970839 |
| Tonnage (tons) | 25 |
| Working weight (kg) | 24670 |
| Bucket capacity (m³) | 1.1 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU CC-6BG1TRP |
| Rated power (kw/rpm) | 125/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 6.494 |
| Rotation speed (rpm) | 12.1 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 163 |
| Rod digging force (kN) | 116 |
| Travel speed (km/h) | 3.5/5.5 |
| Main overflow set pressure (Mpa) | 31.5 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 231 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Main pump type | Plunger pump ×2 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 240 |
| Engine Oil changes (L) | 25 |
| Total transport length (mm) | 10160 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3050 |
| Counterweight ground clearance (mm) | 1085 |
| Minimum ground clearance (mm) | 485 |
| Back end turning radius (mm) | 2940 |
| Total track length (mm) | 4640 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 3842 |
| Maximum digging radius (mm) | 10270 |
| Maximum digging depth (mm) | 6920 |
| Maximum excavation height (mm) | 9670 |
| Maximum unloading height (mm) | 6795 |
| Maximum vertical digging depth (mm) | 6165 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10090 |
| Maximum effective digging depth (mm) | 6720 |
Description
【 Premium Second-hand Excavator Recommendation 】 XCMG XE205, manufactured at the end of 2022, with only 2,500 hours of actual operation, in excellent condition, exempt from inspection, complete procedures, and ready for transfer at any time. Since its launch, this excavator has been highly praised and has won the trust of a large number of users with its outstanding performance and durability. The working hours of this XCMG XE205 excavator are only 2,500 hours, which is equivalent to a nearly brand-new device. Its service life is far from reaching its limit and it has huge potential for use. For buyers who are in pursuit of cost performance, this is undoubtedly a rare and good opportunity. 【 Power System 】 This machine is equipped with a highly efficient and energy-saving engine, which not only has strong power but also excellent fuel economy. After professional testing, the engine operates smoothly with low noise, and can easily handle both complex terrains and high-intensity operations. In addition, the heat dissipation system is reasonably designed and can maintain a good working condition even in high-temperature environments. The hydraulic system is equipped with advanced negative flow control technology, ensuring high operatio
