Product Description
The high-quality XCMG XE250 excavator has been in use since 2010, with a cumulative working time of only over 60,000 hours and maintaining an overall good condition. This equipment is equipped with a high-performance engine (expected model: Weichai WP10), with a maximum power output of up to 139kW, ensuring strong power output and high operational efficiency. In terms of the hydraulic system, an advanced variable piston pump and high-quality hydraulic motor combination are adopted, which can achieve precise control and rapid response. Whether it is excavation, loading or crushing operations, it can handle them with ease. As a classic model that has been verified by the market for a long time, XCMG XE250 not only performs well in durability, but also has received wide acclaim for its operational comfort and maintenance convenience. Its spacious and comfortable cab design, combined with multi-angle adjustable seats, can ensure the driver's best condition even during long working hours. The easily accessible layout of service points greatly simplifies the daily maintenance process and reduces operating costs. To sum up, this second-hand XCMG XE250 excavator, which has a history of ten years but still maintains good condition, with its o
| Specifications | Value |
|---|---|
| No. | 976265 |
| Tonnage (tons) | 25 |
| Working weight (kg) | 24670 |
| Bucket capacity (m³) | 1.1 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU CC-6BG1TRP |
| Rated power (kw/rpm) | 125/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 6.494 |
| Rotation speed (rpm) | 12.1 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 163 |
| Rod digging force (kN) | 116 |
| Travel speed (km/h) | 3.5/5.5 |
| Main overflow set pressure (Mpa) | 31.5 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 231 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Main pump type | Plunger pump ×2 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 240 |
| Engine Oil changes (L) | 25 |
| Total transport length (mm) | 10160 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3050 |
| Counterweight ground clearance (mm) | 1085 |
| Minimum ground clearance (mm) | 485 |
| Back end turning radius (mm) | 2940 |
| Total track length (mm) | 4640 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 3842 |
| Maximum digging radius (mm) | 10270 |
| Maximum digging depth (mm) | 6920 |
| Maximum excavation height (mm) | 9670 |
| Maximum unloading height (mm) | 6795 |
| Maximum vertical digging depth (mm) | 6165 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10090 |
| Maximum effective digging depth (mm) | 6720 |
