Product Description
【 Premium Recommendation 】 Second-hand XCMG XE35 excavator from 2020, with outstanding performance and reliable quality. This equipment has a working time of only 1,500 hours. With proper maintenance, it shows almost no wear and tear, making it an ideal choice for your construction projects. In terms of the power system, this aircraft is equipped with the highly efficient and energy-saving Yanmar 4TNV98 engine, with a maximum power output of 24.5 kilowatts, ensuring strong power output and low fuel consumption performance. Whether it is excavation, crushing or loading operations, they can all be handled with ease, ensuring construction efficiency while reducing operating costs. The hydraulic system adopts an advanced combination of variable piston pumps and high-performance hydraulic motors, featuring rapid response and precise control, providing operators with an excellent operating experience. In addition, its unique load sensing technology can automatically adjust the fuel supply, further enhancing fuel economy and extending the service life of key components. The main advantages include but are not limited to: The compact and flexible design enables the machine to move freely even in confined Spaces; The spacious and comfortable
| Specifications | Value |
|---|---|
| No. | 976198 |
| Tonnage (tons) | 4 |
| Working weight (kg) | 4200/4100 |
| Bucket capacity (m³) | 0.12 |
| Boom length (mm) | 2560 |
| Rod length (mm) | 1350 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 3TNV88-B |
| Rated power (kw/rpm) | 22.2/2400 |
| Cooling mode | water-cooling |
| Displacement (L) | 1.642 |
| Working form | Direct injection, 4 strokes |
| Ground specific pressure (Kpa) | 36.6 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 30 |
| Bucket digging force (kN) | 28.6 |
| Rod digging force (kN) | 20.3 |
| Maximum tractive force (kN) | 31.6 |
| Travel speed (km/h) | 3.6/2.2 |
| Maximum flow of main pump (l/min) | 108 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 16.7 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 40 |
| Hydraulic Tank (L) | 45 |
| Engine Oil changes (L) | 7 |
| Total transport length (mm) | 4970 |
| Total transport width (mm) | 1740 |
| Total transport height (mm) | 2535 |
| Counterweight ground clearance (mm) | 587 |
| Minimum ground clearance (mm) | 297 |
| Minimum turning radius of front working device (mm) | 870 |
| Track gauge (mm) | 1440 |
| Total track width (mm) | 300 |
| Center distance of support wheel (mm) | 1721 |
| Maximum digging radius (mm) | 5300 |
| Maximum digging depth (mm) | 3060 |
| Maximum excavation height (mm) | 5000 |
| Maximum unloading height (mm) | 3600 |
| Maximum vertical digging depth (mm) | 2260 |
| Bulldozer lift or depth (mm) | 305/360 |
| Dodging plate width × height (mm) | 1740*358 |
