| Specifications | Value |
|---|---|
| No. | 966228 |
| Tonnage (tons) | 4 |
| Working weight (kg) | 4050 |
| Bucket capacity (m³) | 0.14 |
| Boom length (mm) | 2795 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 4TNV88 |
| Rated power (kw/rpm) | 27.1/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.19 |
| Ground specific pressure (Kpa) | 23.6 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 23.2 |
| Rod digging force (kN) | 19.3 |
| Travel speed (km/h) | 4.2/2.6 |
| Main overflow set pressure (Mpa) | 21 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*110+11 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 21 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Japan Fujikoshi variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 65 |
| Engine Oil changes (L) | 7.4 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5455 |
| Total transport width (mm) | 1650 |
| Total transport height (mm) | 2440 |
| Counterweight ground clearance (mm) | 578 |
| Minimum ground clearance (mm) | 350 |
| Minimum turning radius of front working device (mm) | 2385 |
| Back end turning radius (mm) | 1490 |
| Track gauge (mm) | 1335 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1721 |
| Maximum digging radius (mm) | 5810 |
| Maximum digging depth (mm) | 3600 |
| Maximum excavation height (mm) | 5320 |
| Maximum unloading height (mm) | 3700 |
| Maximum vertical digging depth (mm) | 2250 |
| Bulldozer lift or depth (mm) | 267/365 |
| Dodging plate width × height (mm) | 1650 x 300 |
Description
【 Premium Recommendation 】 XCMG XE400 excavator produced in 2020, original owner, a leading domestic brand! This XCMG XE400 excavator was officially rolled off the production line in 2020 and has only been in operation for 2,500 hours so far, remaining in its best working condition. As a medium to large-sized excavator, it is equipped with a powerful power system and an efficient hydraulic system, making it an ideal choice for earthwork projects, mining, road construction and other projects. This machine is equipped with a Cummins QSB6.7-C240 engine, with a maximum power output of up to 179kW (approximately 240 horsepower), meeting the national emission standards for non-road mobile machinery. It not only has strong power but also is energy-saving and environmentally friendly. Meanwhile, the high-pressure common rail fuel injection technology it adopts has significantly improved fuel economy and greatly reduced operating costs. The XCMG XE400 is equipped with an advanced negative flow control hydraulic system, featuring fast response and flexible operation, capable of achieving precise excavation and leveling operations. In addition, this machine is also equipped with a variety of safety protection devices, such as overload protecti
