| Specifications | Value |
|---|---|
| No. | 968571 |
| Tonnage (tons) | 4 |
| Working weight (kg) | 4050 |
| Bucket capacity (m³) | 0.14 |
| Boom length (mm) | 2795 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 4TNV88 |
| Rated power (kw/rpm) | 27.1/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.19 |
| Ground specific pressure (Kpa) | 23.6 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 23.2 |
| Rod digging force (kN) | 19.3 |
| Travel speed (km/h) | 4.2/2.6 |
| Main overflow set pressure (Mpa) | 21 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*110+11 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 21 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Japan Fujikoshi variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 65 |
| Engine Oil changes (L) | 7.4 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5455 |
| Total transport width (mm) | 1650 |
| Total transport height (mm) | 2440 |
| Counterweight ground clearance (mm) | 578 |
| Minimum ground clearance (mm) | 350 |
| Minimum turning radius of front working device (mm) | 2385 |
| Back end turning radius (mm) | 1490 |
| Track gauge (mm) | 1335 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1721 |
| Maximum digging radius (mm) | 5810 |
| Maximum digging depth (mm) | 3600 |
| Maximum excavation height (mm) | 5320 |
| Maximum unloading height (mm) | 3700 |
| Maximum vertical digging depth (mm) | 2250 |
| Bulldozer lift or depth (mm) | 267/365 |
| Dodging plate width × height (mm) | 1650 x 300 |
Description
【 Premium Recommendation 】 XCMG XE270 second-hand excavator from 2019, with outstanding quality and stable performance, is your ideal choice for engineering operations. This excavator has only been in operation for 6,400 hours since it left the factory, which is equivalent to one-third of the average lifespan of similar equipment, and it is in the best condition for use. Whether it is urban construction sites or rural infrastructure construction, it can handle them with ease and perform outstandingly. In terms of the power system, this excavator is equipped with a high-quality engine, which features strong power output and smooth operation characteristics. It can maintain efficient operation even in harsh working environments. Meanwhile, its advanced fuel management system can effectively reduce fuel consumption, improve economy and save more costs for users. The hydraulic system adopts the world-leading hydraulic technology, ensuring the flexible operation and rapid response of the entire machine. Whether it is complex operations such as excavation, loading or crushing, they can all be precisely controlled, significantly enhancing work efficiency. In addition, this model is also equipped with multiple safety protection devices, such
