| Specifications | Value |
|---|---|
| No. | 963160 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
Description
【 Premium Recommendation 】 XCMG XE60 Hydraulic excavator from 2018, with outstanding quality and stable performance, is your reliable assistant for construction projects! This XCMG XE60 excavator was manufactured in 2018 and has been in operation for only 2,500 hours so far. It is well maintained and in excellent condition. Its power system is equipped with high-quality Yanmar engines, which feature strong power output and smooth operation characteristics. Even under harsh working conditions, it can maintain efficient operation. Meanwhile, this engine also features excellent fuel economy, significantly reducing your operating costs. In terms of the hydraulic system, XCMG XE60 adopts an advanced load-sensitive hydraulic system, which responds quickly and operates flexibly. Whether it is excavation, loading or crushing operations, it can handle them with ease. In addition, the system has low maintenance costs and high reliability, ensuring stability during long-term operation. This excavator not only has excellent performance but also a neat appearance. The cab is spacious and comfortable with a wide field of vision, providing a good working environment for the operator. More importantly, we have reached an agreement with the buyer an
