| Specifications | Value |
|---|---|
| No. | 964153 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
Description
【 Premium Recommendation 】 The XCMG XGC215 pile driver from 2012 has a total working time of over 6,000 hours. With outstanding quality and stable performance, it is your ideal choice for engineering operations. This pile driver adopts a high-performance hydraulic system imported from Kawasaki, Japan, ensuring that the machine can maintain an efficient and stable working state under various complex working conditions. Its unique hydraulic control technology not only enhances the operational flexibility and response speed of the entire machine, but also significantly extends the service life of the equipment. In terms of power, it is equipped with a high-power engine, which is powerful and has good fuel economy. It can handle both plains and mountains with ease. In addition, this model has undergone strict quality inspection and maintenance. It has a clean appearance, no obvious damage to structural components, and key parts such as the main pump and motor are all in good condition. We promise to provide detailed maintenance records and professional after-sales service support to ensure your purchase is worry-free. Welcome all business owners to come for a test drive experience or call for more details. We look forward to cooperating wi
